Professional immersion gold PCBs manufacturer with UL, RoHS, ISO9001New

Get Latest Price

Payment Type:: T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T

Product Description

PCB layers: 1 to 26

Materials: FR4, high Tg or high CTI FR4, halogen-free FR4, heavy copper FR4

Major base material supplier: Shengyi, Huazheng, KB, International, Nayya

Surface finishing: immersion gold (ENIG), lead-free HAL (hot-air leveling), OSP, immersion tin, immersion silver, hard gold connectors/fingers

Specials: laser drilling, micro blind/buried via, high-frequency, mixed core, heavy copper (up to 6oz), halogen-free base material or halogen-free solder mask, impedance control, edge plated, half PTH, peelable mask, counter sink holes, deep milling, edge beveling, plugged via with resin or solder mask

Solder mask colors: green/matte green, blue/matte blue, white, red, black and more

Component mask colors: green/matte green, blue/matte blue, white, red, black and more

Minimum track space: 3/3-mil

Minimum CNC hole size: 0.15mm

Aspect ratio: 1:8

Outline profiles: punching, routing, punch and push back
