Multiple-parameter Fetal/Maternal Monitor, Portable Design/Built-in FAS/TFT Screen, Monitors CTG

Multiple-parameter Fetal/Maternal Monitor, Portable Design/Built-in FAS/TFT Screen, Monitors CTG

Get Latest Price

Payment Type:: 100% T/T in Advance, PayPal, Western Union, L/C

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	100% T/T in Advance, PayPal, Western Union, L/C

Product Description

Features:

12.1-inch high-resolution colored TFT LCD display and supports plug-in large screen CRT display
Standard configurations: FHR, Toco, fetal movement, ECG, Spo₂, NIBP, RESP, TEMP & pulse rate
Optional twins
Portable and convenient monitor
Built-in rechargeable Li-ion battery, AC-DC power supply, without interruption monitor
Dynamic saving and displays the monitoring information within 48 hours
Supports extension of almost 128 units central monitor system
Quality speaker takes more clear and loud sound

Specifications:

FHR:
- Ultrasound probe: 12-piece chip, multiple wafer, wave beam and high sensitive
- Ultrasound frequency: 1MHz ±5%
- Ultrasound intensity: <3mW/cm²
- FHR range: 30 to 240bpm
- Resolution: 1bpm
- Accuracy: ±1bpm/1%
TOCO:
- TOCO range: 0 to 100 (relative unit)
- Resolution: 1bpm
- Non-linear error: ≤±5%
Fetal movement: button hand count (automatic cumulative number of movements)

NIBP:

Measurement units: mmHg/KPa (optional)
Pressure protection: double security protection software and hardware
Work mode: auto and manual
Measurement intervals: 2 to 60 minutes setup
Surveys:
- Systolic blood pressure range: 60 to 240mmHg
- Average blood pressure range: 40 to 200mmHg
- Diastolic blood pressure range: 30 to 180mmHg
- Resolution: 1mmHg
- Accuracy: ±3mmHg
Pulse rates: 40 to 240bpm

SPO₂:

Range: 70 to 99%
Resolution: 1%
Accuracy: ±2 effective digital
Pulse rate range: 40 to 240bpm

ECG:

Range: 30 to 300bpm
Accuracy: ±1bpm/1%
Choices: I, II, III, aVR, aVL, aVF and V
Scan speeds: 12.5, 25 and 50mm/s
Gain choice: x0.25, x0.5, x1 and x2
Applications: diagnosis, monitoring and surgery

RESP:

Range: 1 to 99rpm
Resolution: 1rpm
Accuracy: ±2rpm

Printer: 50mm usual thermal paper

12.1-inch high-resolution colored TFT LCD display and supports plug-in large screen CRT display

Standard configurations: FHR, Toco, fetal movement, ECG, Spo₂, NIBP, RESP, TEMP & pulse rate

Optional twins

Portable and convenient monitor

Built-in rechargeable Li-ion battery, AC-DC power supply, without interruption monitor

Dynamic saving and displays the monitoring information within 48 hours

Supports extension of almost 128 units central monitor system

Quality speaker takes more clear and loud sound

FHR:

Ultrasound probe: 12-piece chip, multiple wafer, wave beam and high sensitive
Ultrasound frequency: 1MHz ±5%
Ultrasound intensity: <3mW/cm²
FHR range: 30 to 240bpm
Resolution: 1bpm
Accuracy: ±1bpm/1%

TOCO:

TOCO range: 0 to 100 (relative unit)
Resolution: 1bpm
Non-linear error: ≤±5%

Fetal movement: button hand count (automatic cumulative number of movements)

Ultrasound probe: 12-piece chip, multiple wafer, wave beam and high sensitive

Ultrasound frequency: 1MHz ±5%

Ultrasound intensity: <3mW/cm²

FHR range: 30 to 240bpm

Resolution: 1bpm

Accuracy: ±1bpm/1%

TOCO range: 0 to 100 (relative unit)

Resolution: 1bpm

Non-linear error: ≤±5%

Measurement units: mmHg/KPa (optional)

Pressure protection: double security protection software and hardware

Work mode: auto and manual

Measurement intervals: 2 to 60 minutes setup

Surveys:

Systolic blood pressure range: 60 to 240mmHg
Average blood pressure range: 40 to 200mmHg
Diastolic blood pressure range: 30 to 180mmHg
Resolution: 1mmHg
Accuracy: ±3mmHg

Pulse rates: 40 to 240bpm

Systolic blood pressure range: 60 to 240mmHg

Average blood pressure range: 40 to 200mmHg

Diastolic blood pressure range: 30 to 180mmHg

Resolution: 1mmHg

Accuracy: ±3mmHg

Range: 70 to 99%

Resolution: 1%

Accuracy: ±2 effective digital

Pulse rate range: 40 to 240bpm

Range: 30 to 300bpm

Accuracy: ±1bpm/1%

Choices: I, II, III, aVR, aVL, aVF and V

Scan speeds: 12.5, 25 and 50mm/s

Gain choice: x0.25, x0.5, x1 and x2

Applications: diagnosis, monitoring and surgery

Range: 1 to 99rpm

Resolution: 1rpm

Accuracy: ±2rpm
