120m HDMI Extender Over Single Cat5 Wide-band IR, 1080P, HDCP1.2New

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, Western Union, Cash or PayPal

Product Description

Features:

Compliant HDCP 1.2
Uses off-the-shelf gigabit IP switches for extension and distribution
Extends 1080p HDMI signals up to 120m over a single UTP Cat5e/6 cable
Flexible and scalable HDMI 1080p video wall broadcasting with Gigabit Ethernet LAN
Multicasting and broadcasting architecture, adding more displays without adding LAN band width loading
Supports: Point-to-point & point to-many and many-to-many network configuration
With IR control function, it allows you control back the source at the end of destination
Can be cascaded for many layers by adding Ethernet switches
Notice:
- Our company reserve the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice

Specifications:

Operating temperature range: -5 to +35°C (+23 to +95℉)
Operating humidity range: 5 to 90% RH (No condensation)
Input video signal: 0.5-1.0 volts P-P
Input DDC signal: 5 volts p-p(TTL)
Supports video format: DTV/HDTV: 480i/576i/480P/576P/720P/1080i/1080P
Video output: HDMI
Transmission distance: 1080P 8bit 120m (maximum) over single CAT5E/6/24AWG/solid
Power consumption:
- TX: 3 Watts
- RX: 3 Watts (Maximum)
IR wavelength & frequency: Wavelength: 940nm & frequency 38KHz
Dimension (L×W×H): 103.5x93.5x24.6mm
Net weight:
- Receiver: 220g
- Transmitter: 220g
TX default IP address: 192.168.168.55
MAC address: 00:0b:78:00:60:01
RX default IP address: 192.168.168.56
MAC address: 00:0b:78:00:60:02
