Google's Android 4.4 TV Box with DDR3 2G, Quad-core 2.0G and Cortex-A9, Supports OTA FunctionNew

Google's Android 4.4 TV Box with DDR3 2G, Quad-core 2.0G and Cortex-A9, Supports OTA FunctionNew

Get Latest Price

Payment Type:: PayPal or T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	PayPal or T/T

Product Description

System configuration:

CPU: Amlogic S802 quad-core 2.0G (Cortex-A9)
GPU: Octo-core Mali-450
4*2K: yes
RAM: 2G DDR3 (256x16x4), priority
ROM: 16G, priority (8G)
Expand memory: 1*T-flash, supports maximum 32G
Antenna for Wi-Fi

Media:

Video formats: supports multiple video decoding, 4*2K H.264, 1080p
Picture format: JPEG/BMP/GIF/PNG/TIF

Communication:

Ethernet: 10/100M LAN
Wi-Fi can supports 802.11a/b/g/n AP6330/AP6210, priority
PCBA: 6210/6330 co-lay
Bluetooth: BT 4.0, 6210/6330/6330
Sensor/motor: IR sensor, 1*IR
Indicator power: LED, 1*white LED

Button and ports:

Button 1*power button (physical button), control power on and off, definition as bellow:
- Press for 1s, power on
- Press for 1s when OS on to start standby mode, press for 1s again to awake operating system
- Press for 8s to force to power off (TBD)
1*update button (via one pin hole)
USB 2.0 2*standard USB, 4-pin header reserved (built-in USB CAM port)
1*micro USB with OTG
DC-in 1*DC-in jack
HDMI 1* standard: A HDMI 1.4b out, 4*2K
1*standard A HDMI 1.4b output
SPDIF 1*S/SPDIF out (2 and 5.1-ch)
1*RJ45
TF card slot 1*TF card slot
AV 1*AV port
Power management
Adapter: 5V/3A (TBD)

Accessories:

HDMI cable by request
USB data cable by request
Manual by request
USB cable by request
1*adapter, 5V/3A (TBD)

Software configuration:

Operating system: Google Android 4.4, supports OTA function (option)
Language: multiple-language
Keyboard: qwerty
Pre-install: software angry birds by request
Features: Miracast/DLNA supported
Standard: UI
Case graphic slot between top and bottom cover
Texturing on bottom cover and side A of top cover and polishing on side of top cover
Working environment: 5 to 35°C, 30-90% RH

CPU: Amlogic S802 quad-core 2.0G (Cortex-A9)

GPU: Octo-core Mali-450

4*2K: yes

RAM: 2G DDR3 (256x16x4), priority

ROM: 16G, priority (8G)

Expand memory: 1*T-flash, supports maximum 32G

Antenna for Wi-Fi

Video formats: supports multiple video decoding, 4*2K H.264, 1080p

Picture format: JPEG/BMP/GIF/PNG/TIF

Ethernet: 10/100M LAN

Wi-Fi can supports 802.11a/b/g/n AP6330/AP6210, priority

PCBA: 6210/6330 co-lay

Bluetooth: BT 4.0, 6210/6330/6330

Sensor/motor: IR sensor, 1*IR

Indicator power: LED, 1*white LED

Button 1*power button (physical button), control power on and off, definition as bellow:

Press for 1s, power on
Press for 1s when OS on to start standby mode, press for 1s again to awake operating system
Press for 8s to force to power off (TBD)

1*update button (via one pin hole)

USB 2.0 2*standard USB, 4-pin header reserved (built-in USB CAM port)

1*micro USB with OTG

DC-in 1*DC-in jack

HDMI 1* standard: A HDMI 1.4b out, 4*2K

1*standard A HDMI 1.4b output

SPDIF 1*S/SPDIF out (2 and 5.1-ch)

1*RJ45

TF card slot 1*TF card slot

AV 1*AV port

Power management

Adapter: 5V/3A (TBD)
