4G 16dBI LTE High-gain Yagi Outdoor Directional Antenna with Aluminum-alloy Frame

4G 16dBI LTE High-gain Yagi Outdoor Directional Antenna with Aluminum-alloy Frame

Get Latest Price

Payment Type:: TT, Western Union, PayPal, MoneyGram

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	TT, Western Union, PayPal, MoneyGram

Product Description

Features:

High gain
Aluminum-alloy frame
Full day for working
Optimized dimensions
Optional installation H or V

Applications:

4G LTE 2.4GHz WLAN system
Point-to-point and point to point/multiple point transmission system
Wireless bridge, terminal antenna
Wireless AP, wireless adapter

Electric specifications:

Frequency range: 1,800-2,200/2,300-2,600MHz
Bandwidth: 400/300MHz
Gain: 16dBi
Element: 16
Beam width:
- H: 30°
- V: 28°
VSWR: ≤1.5
Input impedance: 50Ω
Polarization: horizontal or vertical
Maximum power: 100W
Lightning protection: DC ground
Connector model: SMA female or others

Mechanical specifications:

Dimensions: 650 x 88 x 44mm
Cable length: 1m
Antenna weight: 0.7kg
Working temperatures: -40 to 60°C
Rated wind velocity: 60m/s
Clamp: U
Pole diameter range: Φ40 to 50mm

High gain

Aluminum-alloy frame

Full day for working

Optimized dimensions

Optional installation H or V

4G LTE 2.4GHz WLAN system

Point-to-point and point to point/multiple point transmission system

Wireless bridge, terminal antenna

Wireless AP, wireless adapter

Frequency range: 1,800-2,200/2,300-2,600MHz

Bandwidth: 400/300MHz

Gain: 16dBi

Element: 16

Beam width:

H: 30°
V: 28°

VSWR: ≤1.5

Input impedance: 50Ω

Polarization: horizontal or vertical

Maximum power: 100W

Lightning protection: DC ground

Connector model: SMA female or others

H: 30°

V: 28°

Dimensions: 650 x 88 x 44mm

Cable length: 1m

Antenna weight: 0.7kg

Working temperatures: -40 to 60°C

Rated wind velocity: 60m/s

Clamp: U

Pole diameter range: Φ40 to 50mm
