Motor Smart Card Reader Module, Can Read and Write IC, Magnetic, RF Cards

Motor Smart Card Reader Module, Can Read and Write IC, Magnetic, RF Cards

Get Latest Price

Payment Type:: Telegraphic Transfer (TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Functions:

Read and write of magnetic cards that comply with 7811standard
Read and write of RF cards that comply with 14443-A and 14443-Bstandards
Read and write of IC cards that comply with EMV standard
Authentication of up to four SIM cards
Communication interface: RS-232
Protection against insertion of other articles
Power failure protection (optional)
Query for card status and determination of card location, aliencard and card reader failure

Technical features:

Industrial design, supporting outdoor application
Integrated ASIC decoder and magnetic head design,anti-interference, large scope of application and good operatingeffect
Dedicated smart card processing chip, highly reliable
Redundant power unit design (large torque of motor), ensuringstable and long-term operating
Built-in precise transmission mechanism, free from mechanicaldamage caused by collision and dust

Performance index:

IC card processing circuit whose electric performance andprotocol comply with EMV standard
Error rate of reading standard and strong magnetic cards:<0.2%
Error rate of reading weak magnetic cards: <2%
Working lifespan: more than 500,000 times of operating
Working voltage: 12V DC ±20%
Maximum current: 2.0A/12V
Power failure protection: when the primary power fails, thestandby power automatically power-off the card and eject the cardby default (the mode depends on the communication protocol)
Dimensions: 145 x 73 x 50mm
Weight: about 0.53kg
Operating temperature: -20 to 55°C
Storage temperature: -40 to 65°C

Applications:

Self-service terminals
Electronic wallets
Automatic vending machines
Multimedia query machines

Read and write of magnetic cards that comply with 7811standard

Read and write of RF cards that comply with 14443-A and 14443-Bstandards

Read and write of IC cards that comply with EMV standard

Authentication of up to four SIM cards

Communication interface: RS-232

Protection against insertion of other articles

Power failure protection (optional)

Query for card status and determination of card location, aliencard and card reader failure

Industrial design, supporting outdoor application

Integrated ASIC decoder and magnetic head design,anti-interference, large scope of application and good operatingeffect

Dedicated smart card processing chip, highly reliable

Redundant power unit design (large torque of motor), ensuringstable and long-term operating

Built-in precise transmission mechanism, free from mechanicaldamage caused by collision and dust

IC card processing circuit whose electric performance andprotocol comply with EMV standard

Error rate of reading standard and strong magnetic cards:<0.2%

Error rate of reading weak magnetic cards: <2%

Working lifespan: more than 500,000 times of operating

Working voltage: 12V DC ±20%

Maximum current: 2.0A/12V

Power failure protection: when the primary power fails, thestandby power automatically power-off the card and eject the cardby default (the mode depends on the communication protocol)

Dimensions: 145 x 73 x 50mm

Weight: about 0.53kg

Operating temperature: -20 to 55°C

Storage temperature: -40 to 65°C

Self-service terminals

Electronic wallets

Automatic vending machines

Multimedia query machines
