4CH Mobile DVR, Supports GPS, 2.5" HDD and USB, with Simultaneous Audio and Video Recording

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Features:

High video quality based on the H.264 high profile
High resolution recording, up to megapixel for 4 channel(1280x1024) and D1 resolution for 1 channel(704x576)
Compact size, much easier for installation
Supports from 8V DC to 32V DC, applicable for 12V DC and 24V DC vehicles
The recorder provides each camera with stable +12V DC power; DVR can detect the shortcut on power circuit
Can use ignition to control the power, configurable power timer after ignition is off
Supports automatic record, event trigger record, schedule record.
Can record speed with audio and video, supports overspeed alarm
Supports 3 sensors, can record brake, return, right turn, left turn light status into the record file
Use AVI format for record file, compatible with different player software
Supports FAT32 file system, record file can be read directly on Windows, Linux

Specifications:

Video video input: 4 channels
Video output: 1 channel, 1.0Vp-p, 75ω, BNC
Video format: supports PAL/NTSC
Video compression: H.264 high profile
Record resolution: 1280x1024(PAL)/1248x832(NTSC)
Frame rate: 100fps(PAL), 120fps(NTSC)
Video bit rate: 1.98Mbps - 4.5Mbps, 4 level video quality
Audio input: 4 channels
Audio input format: 20kω, RCA
Audio output: 1 channel, 500ω, RCA
Audio level: 1V - 2Vp-p
Storage: hard drive, SD card, external USB device (memory stick or hard drive)
File format: AVI
Sensors: 1 speed sensor, 1 ignition sensor, 3 sensors for brake, return and others
Com port: 2 RS232 port, 1 RS485 port
Network: RJ45, 10M/100M
GPS: supports GPS receiver(optional), can record GPS information along with video and audio
GPS data format: Nema0183, baud rate: 4800bps
Software: player: specially designed player for the DVR
Third party software: Windows media player(ver 11.0 or above), VLC media player(ver1.0.0 or above)
Input power: from +8V DC to +40V DC
Power output: DC, +12V@1.5A, +5V@1A
Power consumption:
- Working power: <5W
- strand by power: 0.1W (exclude camera, hard drive, monitor)
Working temperature: from -10°C - +60°C
Size: 180mm x 180mm x 42mm
