4.5-inch Color CCD Plastic Camera with 3.6mm Lens Standard Match

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Product features:

4.5-inch plastic HAICH
Sony/Sharp CCD is optional
420/480/520/540TVL lines is optional
18pcs ofà5mm IR LED
IR auto-open by CDS control in low lux
15m night vision
Standard match: 3.6mm lens

Detailed specifications of the parameters:

CCD type: 1/3-inch Sony CCD
Pixels:

PAL: 795 x 596

NTSC: 811 x 508
Horizontal resolution: 540TVL
Scanning system: PAL/NTSC
Level synchronization frequency:

PAL: 15.625kHz

NTSC: 15.734kHz
Clock frequency:

PAL: 19.3125

NISC: 19.0699
Scanning system: 2:1, deinterlacing
Minimum illumination: 0.1Lux (infrared light to open)
Sync system: synchronization
S/N ratio: 48dB
Electronic shutter:

PAL: 1/50-1/100,000sec

NTSC: 1/60-1/100,000
Gamma correction: 0.45
Video output: 1 Vp-p, 75Ohms
AGC: auto
Night vision: 10m
Power supply: 12V DC (+/-10%)
Current: 400mA
Carton size: 590 x 360 x 200mm
Number of LED: 12pcs
Dimension: 96 x 96 x 63mm
Weight: 0.11kg
Operating temperature: -10 to 45

All trademarks shown here are for reference purposesonly. They are the property of their respective owners, and we arenot authorized to sell items bearing such trademarks.

4.5-inch plastic HAICH

Sony/Sharp CCD is optional

420/480/520/540TVL lines is optional

18pcs ofà5mm IR LED

IR auto-open by CDS control in low lux

15m night vision

Standard match: 3.6mm lens

CCD type: 1/3-inch Sony CCD

Pixels:

PAL: 795 x 596

NTSC: 811 x 508

Horizontal resolution: 540TVL

Scanning system: PAL/NTSC

Level synchronization frequency:

PAL: 15.625kHz

NTSC: 15.734kHz

Clock frequency:

PAL: 19.3125

NISC: 19.0699

Scanning system: 2:1, deinterlacing

Minimum illumination: 0.1Lux (infrared light to open)

Sync system: synchronization

S/N ratio: 48dB

Electronic shutter:

PAL: 1/50-1/100,000sec

NTSC: 1/60-1/100,000

Gamma correction: 0.45

Video output: 1 Vp-p, 75Ohms

AGC: auto

Night vision: 10m

Power supply: 12V DC (+/-10%)

Current: 400mA

Carton size: 590 x 360 x 200mm

Number of LED: 12pcs

Dimension: 96 x 96 x 63mm

Weight: 0.11kg

Operating temperature: -10 to 45
