1D Mobile CCD Barcode Reader for Project Use, KB/RS232/USB interfaces

1D Mobile CCD Barcode Reader for Project Use, KB/RS232/USB interfaces

Get Latest Price

Payment Type:: T/T, Western Union or PayPal

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, Western Union or PayPal

Product Description

Introduction:

LV12 series brings benefits of barcode scanning to various of OEM devices
LV12 series scan module is perfect choice for customer's OEM design
Now kiosks, medical instruments, diagnostic equipment, lottery terminals, vending machines and countless other appliances can all equipped with leading-edge scanning technology and reliability
LV12 barcode scanner series scan module is perfect choice for customer's OEM design
Brings benefits of barcode scanning to all types of OEM devices
Designed to provide highest scanning in smallest package possible
For added versatility, allowing for fast, cost-effective interchangeability when upgrading or modifying your OEM device for specialized applications
Designed with industrial standard size, mounting options and output to facilitate integration into existing applications
Scanner module's miniature size makes LV12 barcode scanner ideal for integration into data terminals and other small devices
LV12 barcode scanner is supplied as an assembled module with mounting bracket or as separate components for custom mounting
Scanner module's unique open system architecture allows LV12 barcode scanner to accept third party and custom plug-in, giving LV12 barcode scanner virtually unlimited application flexibility

Parameters:

Interface: RS232
Image sensor: CCD
Scan rate: 100 scans/sec, ±10%
Light source: visible red light 632nm LED
Reading distance: 230mm at 20mil/0.5mm, PCS90%
Resolution: 5mil/0.127mm at PCS90%
Ambient light: 5,000Lux maximum
Voltage: 5V DC
Operating temperature range: 0 to 50°C
Storage temperature range: 20 to 70°C
Weight:
- Body: approximate 0.56oz (17g)
- Cable: approximate 1.87oz (53g)
Dimension (W x D x H): 44 x 30 x 19.2mm

LV12 series brings benefits of barcode scanning to various of OEM devices

LV12 series scan module is perfect choice for customer's OEM design

Now kiosks, medical instruments, diagnostic equipment, lottery terminals, vending machines and countless other appliances can all equipped with leading-edge scanning technology and reliability

LV12 barcode scanner series scan module is perfect choice for customer's OEM design

Brings benefits of barcode scanning to all types of OEM devices

Designed to provide highest scanning in smallest package possible

For added versatility, allowing for fast, cost-effective interchangeability when upgrading or modifying your OEM device for specialized applications

Designed with industrial standard size, mounting options and output to facilitate integration into existing applications

Scanner module's miniature size makes LV12 barcode scanner ideal for integration into data terminals and other small devices

LV12 barcode scanner is supplied as an assembled module with mounting bracket or as separate components for custom mounting

Scanner module's unique open system architecture allows LV12 barcode scanner to accept third party and custom plug-in, giving LV12 barcode scanner virtually unlimited application flexibility

Interface: RS232

Image sensor: CCD

Scan rate: 100 scans/sec, ±10%

Light source: visible red light 632nm LED

Reading distance: 230mm at 20mil/0.5mm, PCS90%

Resolution: 5mil/0.127mm at PCS90%

Ambient light: 5,000Lux maximum

Voltage: 5V DC

Operating temperature range: 0 to 50°C

Storage temperature range: 20 to 70°C

Weight:
