DVR with 3G function ONVIF and ethernet

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T in Advance, L/C at Sight or Western Union

Product Description

4CH video input

H.264 dual-stream video compression

Full channel @4CH D1 or 4CH CIF realtime recording

4ch audio in & 1ch audio out

Support 1 SATA HDD up to 2TB

Multiple network monitoring: Web viewer、CMS and Mobile phone

Operating system：Embedded LINUX

Video input: 4 channel, BNC

Standard: NTSC(525Line,60f/s),PAL(625Line,50f/s)

Audio input: 4 channel, RCA

Output: 1 channel, RCA

Display interface:1 VGA, 1 BNC, HDMI

Resolution: 800*600;1024*768;1280*1024;1440*900

Display split:1/4

Video/Audio compression: H.264 / G.711

Resolution: D1 (704×576/704×480)/CIF(352×288/352×240)

Record rate: All channel@D1 (25/30fps) or CIF (25/30fps)

Record mode: manual, schedule(Regular(Continuous), MD, Alarm), Stop

Record Interval: 15～60min (default:60min);Pre-record:5sec;Alarm-record: 30～300sec

Video detection: trigger events recording，alarm，video push，email, buzzer

Video detection: motion detection、video loss、HDD loss

Backup mode: USB device/network

Ethernet: RJ-45 port (10/100M)

Network functions: HTTP, IPv4/IPv6, TCP/IP, UPNP, DHCP, DNS, PPPOE, DDNS

Max.user access: 20 users

Mobile phone: iPhone, iPad, Android

Internal HDD: 1 SATA ports, up to 2TB

USB Interface: 3 ports (1 Rear), USB2.0

RS232: yes

RS485: 1 port, For PTZ control
