Original Brand Server RAM, 4GB (2 x 2GB) PC2-3200 DDR2, 400MHz, 240-pin SDRAM Memory Ki

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, Western Union, MoneyGram, PayPal

Product Description

Description:

When upgrading memory DIMMs 1A and 3A must match
DIMMs 5B and 7B DIMMs 2C and 4C and DIMMs 6D and 8D must match and must be installed as a pair
When DIMMs 1A and 3A are populated the system is automatically configured for 2:1 interleaving
When all 4 banks are populated the system is automatically configured for 4:1 interleaving
When four six or eight DIMMs are populated with identical DIMMs the system is automatically configured for bank interleaving

Specifications:

Application: server
Function: REG ECC-DIMM
Port: DIMM 240 pins
Packing: bag
RAM capacity: 4 GB (2 x 2 GB)
Supply voltage: 2.5V
Frequency: 400MHz (PC2-3200)
Data integrity check: ECC
DL140 G2, DL360 G4p, DL380 G4, DL580 G3, DL580 G4, ML350 G4p, ML370 G4, ML570 G3, ML570 G4

Note:

In the online spare configuration the ROM automatically configures the last populated bank as the spare memory
If only banks A and B are populated bank B is the spare bank
If banks A B and C are populated bank C is the spare bank Online spare memory is configured through RBSU
Mirrored Memory uses mirrored banks to provide a high level of memory redundancy
Customer chooses to implement or not: user selectable via BIOS and default is off

When upgrading memory DIMMs 1A and 3A must match

DIMMs 5B and 7B DIMMs 2C and 4C and DIMMs 6D and 8D must match and must be installed as a pair

When DIMMs 1A and 3A are populated the system is automatically configured for 2:1 interleaving

When all 4 banks are populated the system is automatically configured for 4:1 interleaving

When four six or eight DIMMs are populated with identical DIMMs the system is automatically configured for bank interleaving

Application: server

Function: REG ECC-DIMM

Port: DIMM 240 pins

Packing: bag

RAM capacity: 4 GB (2 x 2 GB)

Supply voltage: 2.5V

Frequency: 400MHz (PC2-3200)

Data integrity check: ECC

DL140 G2, DL360 G4p, DL380 G4, DL580 G3, DL580 G4, ML350 G4p, ML370 G4, ML570 G3, ML570 G4

In the online spare configuration the ROM automatically configures the last populated bank as the spare memory

If only banks A and B are populated bank B is the spare bank

If banks A B and C are populated bank C is the spare bank Online spare memory is configured through RBSU

Mirrored Memory uses mirrored banks to provide a high level of memory redundancy

Customer chooses to implement or not: user selectable via BIOS and default is off
