3.5mm Audio Jack Magnetic Card Readers, OMTP and CTIA Swipe Type Mobile Card Readering, Free SDK

3.5mm Audio Jack Magnetic Card Readers, OMTP and CTIA Swipe Type Mobile Card Readering, Free SDK

Get Latest Price

Payment Type:: T/T, PayPal, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, PayPal, Western Union

Product Description

Features:

Professional structure design: with the professional structure design, beyond the traditional magnetic card reader, perfect combined with mobile drivers
Safe and secure: provides safe and secure transactions, provide hardware
based DES encryption
Secret key injection: support to set up a key injection process and software to inject the key through the audio jack into the device
Provides DUKPT key management
Green initiative: no external power required
Superior magstripe reading performance: offers exceptional card reading capabilities in a durable form factor
Easy to use: simple and best to use, with a smart lanyard
Swipe message: set the device to send the error message

Technical specifications:

Interface: audio headphone jack
Environmental:
- Operating temperature: -15 to 55°C (5 to 131°F) non-condensing
- Storage temperature: -30 to 70°C (-22 to 158°F) non-condensing
- Humidity: maximum of 95% non-condensing, dry storage
Weight: 45g
Media thickness: 0.015 (0.381mm) to 0.035 inch (1.12mm)
Certifications: FCC, CE
Lifespan of header: 100,000 cycles minimum
Reference standards: ISO 7811, AAMVA and CA DMV
Track position: 1 and 2 tracks or 2 and 3 tracks
Card thickness: 0.76 to 1.2mm
Operation speed: 3 to 60 inches per second, bidirectional
Operating system supported: iOS series, Android, WP7/WP8
Compatible software: SDK driver
Phone: HTC, Samsung, Motorola, CoolPad, Hedy, iPhone/iPod/iPad, Windows phone series
Error rate: less than 0.5%
Warranty: one year, parts and labor

Professional structure design: with the professional structure design, beyond the traditional magnetic card reader, perfect combined with mobile drivers

Safe and secure: provides safe and secure transactions, provide hardware

based DES encryption

Secret key injection: support to set up a key injection process and software to inject the key through the audio jack into the device

Provides DUKPT key management

Green initiative: no external power required

Superior magstripe reading performance: offers exceptional card reading capabilities in a durable form factor

Easy to use: simple and best to use, with a smart lanyard

Swipe message: set the device to send the error message

Interface: audio headphone jack

Environmental:
