5V 1A Charger for iPhone with UK Plug, 6W Maximum Power

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Specifications:

Output:

Input:

Protections:

Overload: more than 105%, rated output power, protection type:hiccup mode, recovers automatically after fault condition isremoved

Over-voltage: 120 to 160%, protection type: clamp by internalcircuit

Over-temperature: 140 degrees Centigrade typically, protectiontype: shut down O/P voltage, recovers automatically aftertemperature goes down

Voltage: 5V DC

Rated current: 1,000mA

Maximum power: 6W

Ripple: 1% type voltage (maximum)

Voltage tolerance: 5%

Voltage range: 90 to 264V AC

Frequency range: 47 to 63Hz

AC current: 0.3A/115V AC, 0.21A/230V AC

Leakage current: cold start, 30A/115V AC, 50A/230V AC,0.25mA/240V AC (maximum)

Environment:

Working temperature: 0 to 45 degrees Centigrade

Working humidity: 20 to 90% RH (non-condensing)

Storage temperature: -20 to +85 degrees Centigrade

Storage humidity: 10 to 95% RH

Temperature coefficient: +0.03% degrees Centigrade (0 to 45degrees Centigrade)

Vibration: 10 to 500Hz, 2g, 10 minutes/1 cycle, period for 60minutes

Each along X, Y, Z axes

Safety and EMC:

Safety standards: GB8898, GB4943, EN/IEC/UL60950,EN/IEC/UL60065

Withstand voltage: I/P-O/P: 3kV AC

Isolation resistance: I/P-O/P: 100M Ohms/500V DC/25 degreesCentigrade/70% RH

EMI conduction and radiation: compliance to FCC part 15 classB, EN55022, EN61204-3 class B

Harmonic current: compliance to EN61000-3-2,3

EMS immunity: compliance to EN61000-4-2,3,4,5000-4-2,3,4,5

With global certifications
