2.0mm 3m Multi-mode Duplex Fiber-optic Patch Cable with MTRJ and LC Optical Connector, LSZH and PVC

Get Latest Price

Payment Type:: Telegraphic Transfer (TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

The fiber-optic patch cords are mainly used on patch panel orfor the connection between outlets and terminal equipment. Thequality of connectors and fibers are mainly determined by theinsertion loss and return loss

Applications:

High bit rate data transmission

Telecommunications

Testing instruments

Active device terminations

LAN/WAN

FTTX

Features:

SM and MM available

Standard and custom configurations

Meets telecordia-GR-326-CORE specifications

Low insertion loss

Ultra-low back reflection

For 3.0, 2.4, 2.0mm jacket or 900¼m buffer

Specification:

Insertion loss:

SM: d0.2dB

MM: d0.5dB

Return loss:

PC polish: d35dB

UPC polish: d50dB

APC polish: d65dB

Each test insertion loss changes:

Interchangeable test: d0.2dB
The vibration test: d0.1dB (10 to 60Hz, 1.5 mm amplitude)
Tensile tests: d0.1dB (0 to 15Hg tension, 0.9mm fiberexcept)
High temperature testing: d0.2dB (85°C for 100 hours)
Low temperature test: d0.2 to 40 degrees Celsius (dB for 100hours)
The temperature cycling tests: d0.2dB (-40 to 85°C + 5times)
Humidity test: d0.2dB (25 to 65°C, relative humidity 93%,100 hours)

Interchangeable test: d0.2dB

The vibration test: d0.1dB (10 to 60Hz, 1.5 mm amplitude)

Tensile tests: d0.1dB (0 to 15Hg tension, 0.9mm fiberexcept)

High temperature testing: d0.2dB (85°C for 100 hours)

Low temperature test: d0.2 to 40 degrees Celsius (dB for 100hours)

The temperature cycling tests: d0.2dB (-40 to 85°C + 5times)

Humidity test: d0.2dB (25 to 65°C, relative humidity 93%,100 hours)
