Stadium Perimeter LED Display Screen, Used for Football and Basketball Stadiums

Stadium Perimeter LED Display Screen, Used for Football and Basketball Stadiums

Get Latest Price

Payment Type:: T/T or Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or Western Union

Product Description

LED lamps: DIP546, oval

Wavelength:

Red LED: 620 to 630nm
Green LED: 520 to 535nm
Blue LED: 465 to 475nm

LED module:

Pixel pitch: 20mm
Pixel configuration: 2R1G1B
Resolution: 8 x 16 dots
Size: 160 x 320mm

LED cabinet:

Resolution: 64 x 48 dots
Module quantity: 24 pieces
Frame material: black powder-coated steel
Size: 1280 x 960 x 220mm
Weight: 73kg

Screen:

Power consumption:
- Maximum: 650W
- Average: 300 to 500W
Input voltage: 110 to 240V AC
Frequency: 50 or 60Hz
Resolution: 2,500 dots
Brightness: 6,000nits
Brightness: adjustment manually or automatically
Driving method: constant current static

Viewing angle:

Horizontal: 120°
Vertical: 60°

Optimum viewing distance: 20 to 300m

Refreshing frequency: ≥300Hz

Defects rate: ≤0.00001

MTBF: more than 5000 hours

Lifespan: ≥100,000 hours

Protection grade: IP65

Red LED: 620 to 630nm

Green LED: 520 to 535nm

Blue LED: 465 to 475nm

Pixel pitch: 20mm

Pixel configuration: 2R1G1B

Resolution: 8 x 16 dots

Size: 160 x 320mm

Resolution: 64 x 48 dots

Module quantity: 24 pieces

Frame material: black powder-coated steel

Size: 1280 x 960 x 220mm

Weight: 73kg

Power consumption:

Maximum: 650W
Average: 300 to 500W

Input voltage: 110 to 240V AC

Frequency: 50 or 60Hz

Resolution: 2,500 dots

Brightness: 6,000nits

Brightness: adjustment manually or automatically

Driving method: constant current static

Maximum: 650W

Average: 300 to 500W

Horizontal: 120°

Vertical: 60°
