Outdoor LED Video Display for Lease, with 16mm Pixel Pitch, Silan and Epistar LED Chips

Get Latest Price

Payment Type:: T/T or Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or Western Union

Product Description

Pixel pitch:

LED lamp: DIP546/oval/ultra-luminance
Pixel configuration: 2R1G1B

Wavelength:

Red: 628 to 630nm
Green: 520 to 525nm
Blue: 465 to 470nm

Pixel pitch: 16mm

LED chips: Silan and Epistar

LED module:

Size (W x H): 256 x 128mm
Resolution (W x H): 16 x 8 pixel dots

Unit cabinet:

Size (W x H x D): 1,024 x 768 x 175mm
Resolution: 64 x 48 pixel dots

Material: black powder-coated steel

Weight: 47kg

Pixel resolution: 3,906 pixel dots/square meter

Brightness: 10,000 nits

Color temperature: 5,000 to 9,300K (adjustable by software)

Auto-dimming available (100 levels) (for optional)

Viewing angle:

Horizontal: 120°
Vertical: 60°

Optimum viewing distance: 15 to 80 meters

Scanning mode: static

Driving mode: constant current

Gray scale: 4,096

Showing colors: 68 billion kinds

Refreshing frequency: 1,000Hz (adjustable by software)

Picture display mode: dot-to-dot display synchronous with CRT

Signal interface: DVI

Input signal: RF, S-video, RGB, RGBHV, YUV, YC and more

Display formats: 800 x 600, 1,024 x 768, 1,280 x 1,024 and more

Operating systems: Microsoft's Windows Me/NT/XP/2003/7

Programming software: LINSN LED studio

Protection grade: IP65

Heat treatment fans

Working temperature: -50 to 60°C

Storage temperature: -50 to 85°C

Relative humidity: 10 to 95% RH

Display screen lifetime: 100,000 hours

MTBF: 5,000 hours

Out of controlled pixel dots: <0.0001

Whole screen flatness: less than 1mm error in the juncture

Maintenance way: module replacement and LED change

Power supply: 220V AC, 50/60Hz

LED lamp: DIP546/oval/ultra-luminance

Pixel configuration: 2R1G1B

Red: 628 to 630nm

Green: 520 to 525nm

Blue: 465 to 470nm

Size (W x H): 256 x 128mm

Resolution (W x H): 16 x 8 pixel dots

Size (W x H x D): 1,024 x 768 x 175mm

Resolution: 64 x 48 pixel dots

Horizontal: 120°

Vertical: 60°
