Outdoor P16 LED Display for Rental Stage Background, with Movable Structure

Get Latest Price

Payment Type:: T/T or Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or Western Union

Product Description

Technical specification:

LED lamp parameters:
- LED lamps DIP346, oval
- Wavelengths:
  - Red LEDs: 620 to 630nm
  - Green LEDs: 520 to 535nm
  - Blue LEDs: 465 to 475nm
LED module specification:
- Pixel pitch: 16mm
- Pixel configuration: 1R1G1B
- Module resolution: 16 x 8 pixels dots
- Module size: 256 x 128mm
LED cabinet specification (standard cabinet):
- Cabinet size (W x H x D): 1,024 x 1,024 x 175mm
- Cabinet resolution: 64 x 64 pixel dots
- Module quantity: 32pcs
- Cabinet frame material: black powder coating steel
- Cabinet weight: 63kg
Screen parameters:
- LED display screen resolution: 3,906 dots/m²
- LED display screen brightness: 9,500 nits
- Brightness adjustment: manually or automatically
- Driving method: constant current/static
View angle:
- Horizontal: 120°
- Vertical: 60°
Optimum viewing distance: 15 to 300m
Refreshing frequency: 1500Hz (adjustable by software)
Input voltage: 220/50 or 110V AC/60Hz
Maximum power consumption: 1,500W/m²
Average power consumption: 500 to 1,000W/m²
Defects rate: ≤0.00001
MTBF: >5,000 hours
Lifespan: ≥100,000 hours
Protection grade: IP65
Operating temperature: -40 to 60°C
Operating humidity: 10 to 95% RH
Operating system: Microsoft Windows 98/ME/2000/NT/XP

Packing:

Material: wooden box or flight case
Screen weight: 60kg/m²
One case holds one or two cabinets

LED lamp parameters:

LED lamps DIP346, oval
Wavelengths:
- Red LEDs: 620 to 630nm
- Green LEDs: 520 to 535nm
- Blue LEDs: 465 to 475nm

LED module specification:

Pixel pitch: 16mm
Pixel configuration: 1R1G1B
Module resolution: 16 x 8 pixels dots
Module size: 256 x 128mm

LED cabinet specification (standard cabinet):

Cabinet size (W x H x D): 1,024 x 1,024 x 175mm
Cabinet resolution: 64 x 64 pixel dots
Module quantity: 32pcs
Cabinet frame material: black powder coating steel
Cabinet weight: 63kg

Screen parameters:

LED display screen resolution: 3,906 dots/m²
LED display screen brightness: 9,500 nits
Brightness adjustment: manually or automatically
Driving method: constant current/static

View angle:

Horizontal: 120°
Vertical: 60°

Optimum viewing distance: 15 to 300m

Refreshing frequency: 1500Hz (adjustable by software)

Input voltage: 220/50 or 110V AC/60Hz

Maximum power consumption: 1,500W/m²

Average power consumption: 500 to 1,000W/m²

Defects rate: ≤0.00001

MTBF: >5,000 hours

Lifespan: ≥100,000 hours

Protection grade: IP65

Operating temperature: -40 to 60°C

Operating humidity: 10 to 95% RH

Operating system: Microsoft Windows 98/ME/2000/NT/XP

LED lamps DIP346, oval

Wavelengths:

Red LEDs: 620 to 630nm
Green LEDs: 520 to 535nm
Blue LEDs: 465 to 475nm

Red LEDs: 620 to 630nm

Green LEDs: 520 to 535nm

Blue LEDs: 465 to 475nm

Pixel pitch: 16mm

Pixel configuration: 1R1G1B

Module resolution: 16 x 8 pixels dots

Module size: 256 x 128mm

Cabinet size (W x H x D): 1,024 x 1,024 x 175mm

Cabinet resolution: 64 x 64 pixel dots

Module quantity: 32pcs

Cabinet frame material: black powder coating steel

Cabinet weight: 63kg

LED display screen resolution: 3,906 dots/m²

LED display screen brightness: 9,500 nits

Brightness adjustment: manually or automatically

Driving method: constant current/static

Horizontal: 120°

Vertical: 60°

Material: wooden box or flight case

Screen weight: 60kg/m²

One case holds one or two cabinets
