P5mm LED Panels, Sized 2.56m Tall x 8.96m Wide
  • P5mm LED Panels, Sized 2.56m Tall x 8.96m Wide
P5mm LED Panels, Sized 2.56m Tall x 8.96m Wide

P5mm LED Panels, Sized 2.56m Tall x 8.96m Wide

Get Latest Price
Payment Type:
T/T or Western Union
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T or Western Union
Product Description
Product Description
  • LED module specifications:
    • Pixel pitch: 5mm
    • Pixel configuration: RGB (SMD 3-in-1)
    • Module resolution: 32 x 32 pixel dots
    • Module size: 160 x 160mm
  • LED cabinet specifications (standard cabinet)
    • Cabinet size (W x H): 640 x 640mm
    • Cabinet resolution: 128 x 128 pixel dots
    • Module quantity: 16pcs
    • Cabinet frame material: black powder-coated steel (aluminum for option)
    • Cabinet weight: 18kg
  • LED screen parameters:
    • LED screen resolution: 40,000 dots/m²
    • LED screen brightness: 2000 nits
    • Brightness adjustment: manually by software
    • Driving method constant current: 1/16
    • Viewing angle: horizontal 120°, vertical 120°
    • Optimum viewing distance: >4 meters
    • Refreshing frequency: 1000Hz
    • Grayscale: 4096 grades
    • Displaying colors: 69 billion
    • Input voltage full range: 110-240V AC, 50/60Hz
    • Power consumption: maximum: 1000W/m², average: 400-800W/m²
    • Defects rate: ≤0.00001
    • MTBF: >5000 hours
    • Lifespan: ≥100,000 hours
    • Protection grade: IP43
    • Operating temperature: -20 - +60°C
    • Operating humidity: 10 - 95%
    • Operating system: Windows 98/Me/2000/NT/XP
    • Video processor: HDMI, HD-SDI, DVI, VGA
  • Pixel pitch: 5mm
  • Pixel configuration: RGB (SMD 3-in-1)
  • Module resolution: 32 x 32 pixel dots
  • Module size: 160 x 160mm
  • Cabinet size (W x H): 640 x 640mm
  • Cabinet resolution: 128 x 128 pixel dots
  • Module quantity: 16pcs
  • Cabinet frame material: black powder-coated steel (aluminum for option)
  • Cabinet weight: 18kg
  • LED screen resolution: 40,000 dots/m²
  • LED screen brightness: 2000 nits
  • Brightness adjustment: manually by software
  • Driving method constant current: 1/16
  • Viewing angle: horizontal 120°, vertical 120°
  • Optimum viewing distance: >4 meters
  • Refreshing frequency: 1000Hz
  • Grayscale: 4096 grades
  • Displaying colors: 69 billion
  • Input voltage full range: 110-240V AC, 50/60Hz
  • Power consumption: maximum: 1000W/m², average: 400-800W/m²
  • Defects rate: ≤0.00001
  • MTBF: >5000 hours
  • Lifespan: ≥100,000 hours
  • Protection grade: IP43
  • Operating temperature: -20 - +60°C
  • Operating humidity: 10 - 95%
  • Operating system: Windows 98/Me/2000/NT/XP
  • Video processor: HDMI, HD-SDI, DVI, VGA
