P16mm LED Digital Billboard with 5,000-9,300K Color Temperature

P16mm LED Digital Billboard with 5,000-9,300K Color Temperature

Get Latest Price

Payment Type:: T/T or Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or Western Union

Product Description

Pixel LED:

LED lamp DIP546/oval/ultra-brightness
Pixel configuration: 2R1G1B
Wavelength:
- R: 628-630nm
- G: 520-525nm
- B: 465-470nm
Pixel pitch: 16mm
LED chip: Epistar

LED module:

Size (W x H): 256 x 256mm
Resolution (W x H): 16 x 16 pixel dots

LED cabinet:

Size ( W x H x D): 1,024 x 1,024 x 175mm
Resolution: 64 x 64 pixel dots
Material: black powder coated steel
Protection level: IP65
Weight: 62kg

Specifications:

Pixel resolution 3,906 pixel dots/square meter
Brightness: 9,000 nits
Color temperature: 5,000-9,300K (adjustable by software)
Brightness adjustment: available by software by manual at 100 levels
Viewing angle:
- Horizontal: 120°
- Vertical: 60°
Viewing distance: 10-200 meters
Scanning mode: static
Driving mode: constant current
Gray scale: 4096
Showing colors: 68 billion kinds
Refreshing frequency: 1,000Hz (adjustable by software)
Picture display mode: dots to dots display synchronous with CRT
Signal interface: DVI
Input signal: RF, S-video, RGB, RGBHV, YUV, YC and more
Display formats: 800 x 600, 1,024 x 768, 1,280 x 1,024P and more
Operating system: Microsoft's Windows Me/NT/XP/2003/7
Programming software: LINSN LED studio
Protection grade: IP65
Heat-treatment and ventilation: built-in fans
Working temperature: -40 - +60℃
Storage temperature: -40℃ - +85℃
Relative humidity: 10 - 95% RH
Display screen lifetime: ≥100,000 hours
MTBF: ≥5,000 hours
Out of controlled pixel dots: ＜0.0001
Whole screen flatness less than 1mm error in the juncture
Maintenance way module replacement and LED change
Input power voltage full range: 110-240V AC, 50/60Hz

LED lamp DIP546/oval/ultra-brightness

Pixel configuration: 2R1G1B

Wavelength:

R: 628-630nm
G: 520-525nm
B: 465-470nm

Pixel pitch: 16mm

LED chip: Epistar

R: 628-630nm

G: 520-525nm

B: 465-470nm

Size (W x H): 256 x 256mm

Resolution (W x H): 16 x 16 pixel dots

Size ( W x H x D): 1,024 x 1,024 x 175mm

Resolution: 64 x 64 pixel dots

Material: black powder coated steel

Protection level: IP65

Weight: 62kg

Pixel resolution 3,906 pixel dots/square meter

Brightness: 9,000 nits

Color temperature: 5,000-9,300K (adjustable by software)

Brightness adjustment: available by software by manual at 100 levels

Viewing angle:

Horizontal: 120°
Vertical: 60°

Viewing distance: 10-200 meters

Scanning mode: static

Driving mode: constant current

Gray scale: 4096

Showing colors: 68 billion kinds

Refreshing frequency: 1,000Hz (adjustable by software)

Picture display mode: dots to dots display synchronous with CRT

Signal interface: DVI

Input signal: RF, S-video, RGB, RGBHV, YUV, YC and more

Display formats: 800 x 600, 1,024 x 768, 1,280 x 1,024P and more

Operating system: Microsoft's Windows Me/NT/XP/2003/7

Programming software: LINSN LED studio

Protection grade: IP65

Heat-treatment and ventilation: built-in fans

Working temperature: -40 - +60℃

Storage temperature: -40℃ - +85℃

Relative humidity: 10 - 95% RH

Display screen lifetime: ≥100,000 hours

MTBF: ≥5,000 hours

Out of controlled pixel dots: ＜0.0001

Whole screen flatness less than 1mm error in the juncture

Maintenance way module replacement and LED change

Input power voltage full range: 110-240V AC, 50/60Hz

Horizontal: 120°

Vertical: 60°
