Single-point Load Cell, High Accuracy

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Advanced TT, T/T, PayPal, Western Union

Product Description

Features and applications:

Aluminum single point load cell
High accuracy, very good eccentric/deviated load tolerance, and simple structure, easy to install
Suitable for small powder grinding machines
Capacities: 2, 5, 10, 20, 30, 50kg

Specifications:

Aluminum single point load cell

High accuracy, very good eccentric/deviated load tolerance, and simple structure, easy to install

Suitable for small powder grinding machines

Capacities: 2, 5, 10, 20, 30, 50kg

Rated output: 1.5 ± 10% mV/V

Zero balance: ±2% FS

Non-linearity: 0.5% FS

Hysteresis: 0.5% FS

Repeatability: 0.5% FS

Creep (30min): 0.5 % FS

Temperature effect on output: 0.05% FS/10°C

Temperature effect on zero: 0.05% FS/10°C

Input impedance: 410 ±10Ω

Output impedance: 350 ±5Ω

Insulation: ≥5,000MΩ/100V DC

Recommended excitation: 5-10V

Maximum excitation: 15V

Compensated temperature range: -10 - 60°C

Operation temperature range: -20 - 80°C

Safe overload: 120%

Ultimate overload: 150%

Cable size: Ø 3 x 2m

Wire connection:

Ex+: red

Ex-: black

Output+: green

Output -: white
