Miniature Compression Load Cell, -20 to 80°C Operating Temperature

Miniature Compression Load Cell, -20 to 80°C Operating Temperature

Get Latest Price

Payment Type:: T/T in Advance, PayPal, Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T in Advance, PayPal, Western Union

Product Description

Features:

Stainless steel material with oil-proof and waterproof, anti-corrosion, can be worked in all types of environment.
Diaphragm capsule structure, compression bearing and easy to install
Mainly applied in tension and compression testing instruments, automatic equipments and testing fields, such as insertion force test instruments, riveting machine, welding machine, hot/cold lamination machine, feeling tester for keyboard switch
Capacitiy:
- 50kg to 2T: M12
- 2.5 to 5T: M16

Specifications:

Rated output: 2.0mV/V ±10%
Zero balance: ±2% FS
Non-linearity: 0.5% FS
Hysteresis: 0.5% FS
Repeatability: 0.5% FS
Creep (30 minimum): 0.5% FS
Temperature effect on output: 0.05% FS/10°C
Temperature effect on zero: 0.05% FS/10°C
Input impedance: 385 ±5Ω
Output impedance: 350 ±5Ω
Insulation resistance: ≥5000MΩ/50V DC
Recommended excitation: 5 to 10V
Maximum excitation: 15V
Compensated temperature range: -10 to 60°C
Operating temperature range: -20 to 80°C
Safe overload: 150%
Ultimate overload: 200%
Cable size: Ø4 x 2m

Wire connection:

Ex+: red
Ex-: black
Output+: green
Output -: white
