Car Coating Thickness Gauge Meter

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C or D/P

Product Description

Coating thickness gauge meter

Features:

Specifications:

Benefits:

Applications:

If you need other measured ranges, please contact us for help

Including F and N probe

Easy to do zero calibration and multi-point calibration

128*128 dot matrix LCD display and menu interface

Readings can be stored, recalled and deleted

Connect with PC via USB and support analysis software

Two measure mode: single and continuous

Two group mode: direct (DIR) and general (GEN)

User can set high or low limit alarm for each group

Measuring principle: magnetic induction

Measuring range: 0 to 1300um (0 to 51.18mils)

Accuracy: ±(3%+2um)

Calibration: one point to four point calibration, zero point calibration

Statistics: number of readings, mean, minimum, maximum and standard deviation

Units: um, mm and mils

Computer interface: download data via USB interface

Supports analysis software

Operating environment temperatures: 0 to 40°C (32 to 104°F)

Humidity range: 20 to 90% RH

Storage environments: -20 to 70°C (-4 to 158°F)

Size: 110x53x24mm (4.33x2.09x0.94 inches)

High accuracy

Easy to use

Automobile lacquer detection

Ships, aircraft, containers, equipment manufacturing industry

Paint, coating, thin film processing and testing

Electroplating
