50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return
  • 50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return
  • 50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return
  • 50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return
  • 50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return
  • 50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return
  • 50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return
50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return
50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return
50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return
50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return
50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return
50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return

50m HDMI Extender, Over Single UTP Cables with IR Bidirectional Return

Get Latest Price
Payment Type:
Telegraphic Transfer (TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer (TT,T/T)
Product Description
Product Description
  • Introduction:
    • The HDMI extender over 1 UTP cables with IR control is the right way to send your HDMI signal over long distances
    • Instead of using expensive HDMI cables, this device lets you use your existing Cat5e/ 6 cables/sockets while also performing the same functions like transferring HDMI video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, all with a bandwidth up to 165MHz
    • And if that weren’t enough, you can use your existing remote to control your device through an IR blaster
  • Features:
    • Compliant with HDMI 1.3, HDCP 1.1 and DVI1.0 standards
    • Supports digital video formats in 1,080p and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) Digital audio
    • Equalizes and recovers incoming TMDS data before re-transmitting it in high-quality, regardless of the incoming signal quality
    • Supports HDMI1.4 with 3D, ARC function
    • Super IR control system, IR transport channel can be forward or backward
    • Support HDMI loop out
  • Package contents:
    • HDMI transmitter: 1 piece
    • HDMI receiver: 1 piece
    • 5V/1A DC power adaptor: 2 pieces
    • Operating manual: 1 piece
    • Wideband IR: T x 2 pieces
    • Wideband IR: R x 2 pieces
  • Specifications:
    • Transmitter ports: 2 × HDMI (female type), 1 x Cat5e/6,2x3.5mm phone
    • Receiver ports: 1 x HDMI (female type), 1xRCA, 1x Cat5e/6,2x3.5mm phone
    • Support resolution: 480i~1,080p50/60, VGA~UXGA
    • ESD protection:
      • Human body model: ±8kV (air-gap discharge), ±4kV (contact discharge)
    • Power supply: 5V DC/1A
    • Dimensions (W x D x H):  65 × 118 × 26mm
    • Weight: 410g (TX+RX)
    • Chassis material: metal
    • Silkscreen color: black
    • Operating temperature: 0~40°C/ 32~104°F
    • Storage temperature: -20~60°C/-4~140°F
    • Relative humidity: 20~90% RH (non-condensing)
    • Power consumption: 3.2W (transmitter), 2.2W (receiver)
  • The HDMI extender over 1 UTP cables with IR control is the right way to send your HDMI signal over long distances
  • Instead of using expensive HDMI cables, this device lets you use your existing Cat5e/ 6 cables/sockets while also performing the same functions like transferring HDMI video and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, all with a bandwidth up to 165MHz
  • And if that weren’t enough, you can use your existing remote to control your device through an IR blaster
  • Compliant with HDMI 1.3, HDCP 1.1 and DVI1.0 standards
  • Supports digital video formats in 1,080p and new lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) Digital audio
  • Equalizes and recovers incoming TMDS data before re-transmitting it in high-quality, regardless of the incoming signal quality
  • Supports HDMI1.4 with 3D, ARC function
  • Super IR control system, IR transport channel can be forward or backward
  • Support HDMI loop out
  • HDMI transmitter: 1 piece
  • HDMI receiver: 1 piece
  • 5V/1A DC power adaptor: 2 pieces
  • Operating manual: 1 piece
  • Wideband IR: T x 2 pieces
  • Wideband IR: R x 2 pieces
  • Transmitter ports: 2 × HDMI (female type), 1 x Cat5e/6,2x3.5mm phone
  • Receiver ports: 1 x HDMI (female type), 1xRCA, 1x Cat5e/6,2x3.5mm phone
  • Support resolution: 480i~1,080p50/60, VGA~UXGA
  • ESD protection:
    • Human body model: ±8kV (air-gap discharge), ±4kV (contact discharge)
  • Power supply: 5V DC/1A
  • Dimensions (W x D x H):  65 × 118 × 26mm
  • Weight: 410g (TX+RX)
  • Chassis material: metal
  • Silkscreen color: black
  • Operating temperature: 0~40°C/ 32~104°F
  • Storage temperature: -20~60°C/-4~140°F
  • Relative humidity: 20~90% RH (non-condensing)
  • Power consumption: 3.2W (transmitter), 2.2W (receiver)
  • Human body model: ±8kV (air-gap discharge), ±4kV (contact discharge)
