Product Description
Product Description
  • Features:
    • Four outputs of them are unlimited when the corresponding loop is permanently covered, while the others are multiple mode that can be set by users
    • Direction detecting function can be used to statistics the vehicle flux
    • Principle is based on a change in the inductance within the loop which is caused by the metallic components of passing vehicles
    • Changes are picked up and evaluated by microprocessor
    • Ease of use due to automatic calibration when the operating voltage is applied
  • Specifications:
    • Power: 2.5W
    • Working voltages: 110 to 220V AC and 12 to 24V DC (optional)
    • Frequency range: 20 to 170kHz
    • Sensitivity: 3 grades are adjustable
    • Reaction time: 100ms
    • Environmental compensation: automatic drift compensation
    • Loop inductance:
    • Ideal: 80 to 300H (including connection line)
    • Maximum: 50 to 500H (including connection line)
    • Loop connection wiring: 5m (maximum), twisted 20 times at least per meter
    • Total resistance: ≤10
    • Temperatures:
      • Operating: -20 to 65°C
      • Storage: -20 to 85°C
      • Relative humidity: ≤95% (maximum)
    • Size: 85 x 74 x 36mm
  • Four outputs of them are unlimited when the corresponding loop is permanently covered, while the others are multiple mode that can be set by users
  • Direction detecting function can be used to statistics the vehicle flux
  • Principle is based on a change in the inductance within the loop which is caused by the metallic components of passing vehicles
  • Changes are picked up and evaluated by microprocessor
  • Ease of use due to automatic calibration when the operating voltage is applied
  • Power: 2.5W
  • Working voltages: 110 to 220V AC and 12 to 24V DC (optional)
  • Frequency range: 20 to 170kHz
  • Sensitivity: 3 grades are adjustable
  • Reaction time: 100ms
  • Environmental compensation: automatic drift compensation
  • Loop inductance:
  • Ideal: 80 to 300H (including connection line)
  • Maximum: 50 to 500H (including connection line)
  • Loop connection wiring: 5m (maximum), twisted 20 times at least per meter
  • Total resistance: ≤10
  • Temperatures:
    • Operating: -20 to 65°C
    • Storage: -20 to 85°C
    • Relative humidity: ≤95% (maximum)
  • Size: 85 x 74 x 36mm
  • Operating: -20 to 65°C
  • Storage: -20 to 85°C
  • Relative humidity: ≤95% (maximum)
