CCTV Power Supply for Cameras, 24W, 24V/2A, Sized 95 x 52 x 32mm
  • CCTV Power Supply for Cameras, 24W, 24V/2A, Sized 95 x 52 x 32mm
  • CCTV Power Supply for Cameras, 24W, 24V/2A, Sized 95 x 52 x 32mm
CCTV Power Supply for Cameras, 24W, 24V/2A, Sized 95 x 52 x 32mm
CCTV Power Supply for Cameras, 24W, 24V/2A, Sized 95 x 52 x 32mm

CCTV Power Supply for Cameras, 24W, 24V/2A, Sized 95 x 52 x 32mm

Get Latest Price
Payment Type:
T/T
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T
Product Description
Product Description
  • Features:
    • With plastic crust
    • Reliability
    • Built-in over-voltage, over-current and short-circuit protections
    • Certificates: CE, CCC and UL
  • Specifications:
    • Input:
      • Voltage: 100 to 240V AC
      • Frequency: 50/60Hz, less than 1A
      • Maximum line regulation range: 0.5%
      • Start up current: 40A/230V AC
    • Output:
      • Maximum line regulation range: 0.5%
      • Ripple and noise: less than 1% (mVp-p) of output voltage
      • Adjustable range of output voltage: +5 and -3%
      • Start-up time: 1 second (input 240V AC and Io 100%)
      • Hold-up time 20 minutes (input 240V AC and Io 100%)
    • Protections:
      • Overloading: 115 to 150% of rated power, when it happened, the power shuts down automatically and when trouble removed the power recovers itself
      • Over-voltage: 130 to 150% of rated voltage
      • Short-circuit
    • Insulation intensity: 3,000V/10mA, 60 seconds (input/output)
    • Insulation resistance: 500V DC (input/output)
    • Temperature:
      • Operating temperature: 0 to 40°C
      • Storage temperature: -20 to 85°C
    • Humidity:
      • Operating humidity range: 10 to 90% RH (no freezing dew)
      • Storage humidity range: 10 to 95% RH (no freezing dew)
    • Elevation: less than 3,000m
    • EMC: EN55022B and GB9254
    • Dimensions: 95 x 52 x 32mm
    • Weight: 300g
  • With plastic crust
  • Reliability
  • Built-in over-voltage, over-current and short-circuit protections
  • Certificates: CE, CCC and UL
  • Input:
    • Voltage: 100 to 240V AC
    • Frequency: 50/60Hz, less than 1A
    • Maximum line regulation range: 0.5%
    • Start up current: 40A/230V AC
  • Output:
    • Maximum line regulation range: 0.5%
    • Ripple and noise: less than 1% (mVp-p) of output voltage
    • Adjustable range of output voltage: +5 and -3%
    • Start-up time: 1 second (input 240V AC and Io 100%)
    • Hold-up time 20 minutes (input 240V AC and Io 100%)
  • Protections:
    • Overloading: 115 to 150% of rated power, when it happened, the power shuts down automatically and when trouble removed the power recovers itself
    • Over-voltage: 130 to 150% of rated voltage
    • Short-circuit
  • Insulation intensity: 3,000V/10mA, 60 seconds (input/output)
  • Insulation resistance: 500V DC (input/output)
  • Temperature:
    • Operating temperature: 0 to 40°C
    • Storage temperature: -20 to 85°C
  • Humidity:
    • Operating humidity range: 10 to 90% RH (no freezing dew)
    • Storage humidity range: 10 to 95% RH (no freezing dew)
  • Elevation: less than 3,000m
  • EMC: EN55022B and GB9254
  • Dimensions: 95 x 52 x 32mm
  • Weight: 300g
  • Voltage: 100 to 240V AC
  • Frequency: 50/60Hz, less than 1A
  • Maximum line regulation range: 0.5%
  • Start up current: 40A/230V AC
  • Maximum line regulation range: 0.5%
  • Ripple and noise: less than 1% (mVp-p) of output voltage
  • Adjustable range of output voltage: +5 and -3%
  • Start-up time: 1 second (input 240V AC and Io 100%)
  • Hold-up time 20 minutes (input 240V AC and Io 100%)
  • Overloading: 115 to 150% of rated power, when it happened, the power shuts down automatically and when trouble removed the power recovers itself
  • Over-voltage: 130 to 150% of rated voltage
  • Short-circuit
  • Operating temperature: 0 to 40°C
  • Storage temperature: -20 to 85°C
  • Operating humidity range: 10 to 90% RH (no freezing dew)
  • Storage humidity range: 10 to 95% RH (no freezing dew)
