10x Optical Focus Waterproof IR Speed Dome Camera, 700TVL, IP66

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Model no .: JYD-H4RO-S

Image sensor: 1/3" Sony CCD

Signal mode: PAL/NTSC

Horizontal resolution: 700TVL

Effective pixel: 976（Horizontal）x 596（Vertical）

Minimum illumination: color to B/W, color: 0.1 lux, B/W:0.01 lux

S/N ratio: >60dB (enhanced)

Backlight compensation: on/off

White balance: automatic

Electronic shutter: 1/50-1/12,000 seconds

Focus length: 5-50mm

Optical focus: 10X

Focus: auto/manual/push auto, the use of high-performance DSP

to realize complete digit and ultra-high speed focus function

Presets: 256

IR distance: 50m

Protection level: IP66

Patrol track: 4 groups, each can record 200 actions

Cruise track: total 30 presets can join cruise, can setting the presets' residence time

Other scan: supports horizontal scan, deuce area scan, scan random

Rotation range: horizontal 360° unlimited rotation, vertical 90°, auto reversal

Rotation speed: horizontal and vertical minimum of 0.01°, maximum of 200°/S

Communications: RS-485, Pelco D, Pelco P

OSD: yes

Power supply: DC 12V/2A

Work environment temperatures: -20-50°C (select temperature control accessories), <95% RH

Characteristic:

Rotate 360° in horizontal direction, driven by exact engine, operate stably with precise position-setting
The rotation speed can be adjustable according to the zoom rate of camera lens, auto-focus, auto white balance
Built-in OSD, several control protocols are compatible and baud rate is adjustable
Vertical 90° continuous monitoring after auto reversing 180°

Rotate 360° in horizontal direction, driven by exact engine, operate stably with precise position-setting

The rotation speed can be adjustable according to the zoom rate of camera lens, auto-focus, auto white balance

Built-in OSD, several control protocols are compatible and baud rate is adjustable

Vertical 90° continuous monitoring after auto reversing 180°
