Smart Bias Tee, Provides Low-RF Signal Insertion, Loss from Port 1 to 2, 698-2,700MHz Frequency

Smart Bias Tee, Provides Low-RF Signal Insertion, Loss from Port 1 to 2, 698-2,700MHz Frequency

Get Latest Price

Payment Type:: TT, L/C, Western Union or PayPal

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	TT,L/C, Western Union or PayPal

Product Description

Features:

The smart bias tee combines the performance of the function of an additional modem (AISG standard) in order to provide either DC voltage as well as remote control signals via an RF feeder cable to a TMA or RCU
The smart bias tee provides low-RF signal insertion loss from port 1 to port 2 and vice versa
The measures taken to protect against static discharge lightning ensure a high-level of reliability and operating safety
86005951 + 10 + 30 V DC version for use near the BTS, in order to feed-in DC voltage and RCU control signals into a feeder cable

Technical date:

Frequency range: 698-2,700MHz
Insertion loss: port 1 - 2
<0.05dB (698-2,700MHz)
Isolation for DC and RCU signals
Port 1 - 2: >70dB
Port 1 - DC/RCU: >70dB
Port 2-DC/RCU: >0dB
VSWR: <1.10 (698-2,700MHz)
Impedance: 50Ω
Port 1 or port 2: <750W (698-2,700MHz)
Port DC/RCU: <2.5A/+10 to 30V DC
Power consumption: typically 0.6W
Lightning protection: 3kA, 10/350 us pulse
Inter modulation products: <160dBc (3rd order, with 2 x 20W)
Temperature range: –40 to +60°C
Modem carrier frequency: 2.176MHz

The smart bias tee combines the performance of the function of an additional modem (AISG standard) in order to provide either DC voltage as well as remote control signals via an RF feeder cable to a TMA or RCU

The smart bias tee provides low-RF signal insertion loss from port 1 to port 2 and vice versa

The measures taken to protect against static discharge lightning ensure a high-level of reliability and operating safety

86005951 + 10 + 30 V DC version for use near the BTS, in order to feed-in DC voltage and RCU control signals into a feeder cable

Frequency range: 698-2,700MHz

Insertion loss: port 1 - 2

<0.05dB (698-2,700MHz)

Isolation for DC and RCU signals

Port 1 - 2: >70dB

Port 1 - DC/RCU: >70dB

Port 2-DC/RCU: >0dB

VSWR: <1.10 (698-2,700MHz)

Impedance: 50Ω
