Standard Battery Charger for NiMH Battery Pack, with Microprocessor Control

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer (TT,T/T)

Product Description

Rated input voltage: 100 to 240V AC, 50/60Hz

Input voltage range: 90 to 264V AC

Rated input current: 0.1A (input: 220V and output: fullload)

Maximum input power: 8W

Battery specification: 3.6V to 7.2V, 0.6 to 3Ah of NiMH/NiCdbatteries

Rated output voltage: 9V

Output voltage range: 3.6 to 9.6V

Maximum output voltage: 13.2V

Rated charge current: 0.6A

Charge current range: 0.54 to 0.72A

Trickle charge current: <15mA

Output short-circuits current: <15mA

Timer protection: 6/10 hours

Maximum output power: 7.2W

Charge method: pulse

Trickle switch condition after finishing quick charge:

DV e5 to 10mV/cell (TYP)

dT/dt e1/s

Time out or T e50+/-2(NTC)

LED display:

Red charging

Red and green quick flashing, output short or batteryreverse

Red and green slow flashing, battery repair

Green standby or trickle

Output short-circuit protection: yes

Output reverse protection: yes

Charge efficiency: >80% at maximum load

Operating temperature range: -10 to 40 degree Celsius

Operating humidity range: < 90% RH

Storage temperature: -40 to 70 degree Celsius

Storage humidity: 0 to 95%

Cooling: natural convection

Input and output terminals: customer specified

Vibration test: 5mm, 50Hz, 600s

Impact test: 0.8m drop test, 3 times

Safety standard: CE-LVD, CCC, UL

EMC characteristics: CE-EMC, FCC, CCC, UL
