10.2-inch BNC Monitor, Open-frame Metal Case Optional, 800 x 480 Pixels Best Resolution

Get Latest Price

Payment Type:: T/T in Advance, PayPal or Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T in Advance, PayPal or Western Union

Product Description

Specifications:

Display panel: 10.2-inch TFT LCD panel (4:3)
Best resolution: 800 x 480 pixels (1,024 x 768 or 800 x 600 pixels optional)
Contrast ratio: 400:1
Luminance: 250cd/m²
Viewing angle:
H: 160°, V: 140°
Refresh rate: 60 to 75Hz
Signal interface: VGA/AV/BNC (optional)
S-systems: PAL, NTSC
Panel backlight: CCFL double light
Image reversed: not supported
Power input adapter: 110 to 220V
Power output adapter: 12V
Product weight: 1.9kg
Product dimensions: 26.1 x 20.1 x 4.5mm
Menu language: English, Russian, French, Spanish, German, Italian, Chinese
Support VGA/RCA/ BNC/ TV input (optional)
Built-in speaker with earphones jack to connect with earphone or sound-box

Packaging:

Unit packing weight : 2kg
Unit packing dimensions: 31 x 11 x 3cm
Carton weight: 21kg
Carton box dimensions: 60 x 32.5 x 62.5cm

Accessories:

Manual, warranty card, stand, BNC/VGA cable (BNC input)/VGA cable, TV cable and remote control (TV input)/no cable (VGA input), AC power adapter and Ultra-thin design

Main applications:

Microscopes, endoscopy, flatness detectosr, dimensional detectors, hot press, BGA rework station, laser engraving equipment, laser marking machines, rocker cameras, CCTV monitors and POS systems

Display panel: 10.2-inch TFT LCD panel (4:3)

Best resolution: 800 x 480 pixels (1,024 x 768 or 800 x 600 pixels optional)

Contrast ratio: 400:1

Luminance: 250cd/m²

Viewing angle:

H: 160°, V: 140°

Refresh rate: 60 to 75Hz

Signal interface: VGA/AV/BNC (optional)

S-systems: PAL, NTSC

Panel backlight: CCFL double light

Image reversed: not supported

Power input adapter: 110 to 220V

Power output adapter: 12V

Product weight: 1.9kg

Product dimensions: 26.1 x 20.1 x 4.5mm

Menu language: English, Russian, French, Spanish, German, Italian, Chinese

Support VGA/RCA/ BNC/ TV input (optional)

Built-in speaker with earphones jack to connect with earphone or sound-box

Unit packing weight : 2kg

Unit packing dimensions: 31 x 11 x 3cm

Carton weight: 21kg

Carton box dimensions: 60 x 32.5 x 62.5cm

Manual, warranty card, stand, BNC/VGA cable (BNC input)/VGA cable, TV cable and remote control (TV input)/no cable (VGA input), AC power adapter and Ultra-thin design

Microscopes, endoscopy, flatness detectosr, dimensional detectors, hot press, BGA rework station, laser engraving equipment, laser marking machines, rocker cameras, CCTV monitors and POS systems
