12-inch Black and White Medical Display with 800TVL

Get Latest Price

Payment Type:: T/T in Advance, PayPal or Western Union

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T in Advance, PayPal or Western Union

Product Description

Features:

More than 800TVL of horizontal resolution, automatic frequency control line time is adjustable, adjustable scan size, scan or overscan, CCIR, EIA standard compatible video input and output BNC connectors
CCTV can be used as a monitor or video inspection/playback monitor
Loop through connection
Electronic circuits to provide anti-interference, noise and safety protection of the signal intensity change, for maintaining a clear and stable image

Specifications:

CRT: 12-inch diagonal 90° deflection angle
Dimensions: 295x320x280mm
Definition: 800TVL
Outcast: light gray
Frequency characteristic: 10-50Hz
Weight: 9.8kg
Video input: 0.5-2Vp-p, 75Ω BNC socket
Power supply: 200/240V AC, 50/60Hz
Input impedance: Hi-Z/75Ω switch
Power consumption: 27W
Output impedance: 10K Ohms above
Temperature range: 10-50°C

More than 800TVL of horizontal resolution, automatic frequency control line time is adjustable, adjustable scan size, scan or overscan, CCIR, EIA standard compatible video input and output BNC connectors

CCTV can be used as a monitor or video inspection/playback monitor

Loop through connection

Electronic circuits to provide anti-interference, noise and safety protection of the signal intensity change, for maintaining a clear and stable image

CRT: 12-inch diagonal 90° deflection angle

Dimensions: 295x320x280mm

Definition: 800TVL

Outcast: light gray

Frequency characteristic: 10-50Hz

Weight: 9.8kg

Video input: 0.5-2Vp-p, 75Ω BNC socket

Power supply: 200/240V AC, 50/60Hz

Input impedance: Hi-Z/75Ω switch

Power consumption: 27W

Output impedance: 10K Ohms above

Temperature range: 10-50°C
