25MHz SMD crystal 5032, high frequency stability and high reliability, RoHS and Pb Free compliant
  • 25MHz SMD crystal 5032, high frequency stability and high reliability, RoHS and Pb Free compliant
25MHz SMD crystal 5032, high frequency stability and high reliability, RoHS and Pb Free compliant

25MHz SMD crystal 5032, high frequency stability and high reliability, RoHS and Pb Free compliant

Get Latest Price
Payment Type:
Telegraphic Transfer (TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer (TT,T/T)
Product Description
Product Description
  • Features:
    • Ultra-thin, thickness 1.0mm
    • Leadless type
    • High-precision characteristic covering up to high-frequencyrange from 10MHz ~ 48MHz.
    • Designed for automatic mounting and re-flow soldering
    • RoHS and Pb Free compliant.
    • High frequency stability and high reliability.
    • Embossed taping specification
  • Electrical specifications:
    • Frequency: 25MHz
    • Frequency tolerance (at 25°C): ±30 to ±50ppm,specify
    • Frequency stability over-operating temperature: ±30 to±50ppm, specify
    • Storage temperature range: -55 to +125°C
    • Operating temperature range: -10 to +60, -20 to +70 and -40 to+85°C
    • Shunt capacity (C0): 5.0pF (maximum)
    • Drivel level: 10 to 100¼W
    • Loading capacitance (CL): series, 16, 20, 30 and 32pF orspecify
    • Aging (at 25°C): ±3ppm/year
    • Shock resistance: drop test of 3 times on 2mm stainless platefrom 75cm height
  • Applications:
    • Ideally suited designed for disc drives, NB, MID, GPS,Automootive, Game Pad, Bluetooth, PCs and hand-held electronicproducts
  • Ultra-thin, thickness 1.0mm
  • Leadless type
  • High-precision characteristic covering up to high-frequencyrange from 10MHz ~ 48MHz.
  • Designed for automatic mounting and re-flow soldering
  • RoHS and Pb Free compliant.
  • High frequency stability and high reliability.
  • Embossed taping specification
  • Frequency: 25MHz
  • Frequency tolerance (at 25°C): ±30 to ±50ppm,specify
  • Frequency stability over-operating temperature: ±30 to±50ppm, specify
  • Storage temperature range: -55 to +125°C
  • Operating temperature range: -10 to +60, -20 to +70 and -40 to+85°C
  • Shunt capacity (C0): 5.0pF (maximum)
  • Drivel level: 10 to 100¼W
  • Loading capacitance (CL): series, 16, 20, 30 and 32pF orspecify
  • Aging (at 25°C): ±3ppm/year
  • Shock resistance: drop test of 3 times on 2mm stainless platefrom 75cm height
  • Ideally suited designed for disc drives, NB, MID, GPS,Automootive, Game Pad, Bluetooth, PCs and hand-held electronicproducts
