AC/DC Switching Power Supply with 100 to 240V AC Rate Voltage and 12W Power
  • AC/DC Switching Power Supply with 100 to 240V AC Rate Voltage and 12W Power
  • AC/DC Switching Power Supply with 100 to 240V AC Rate Voltage and 12W Power
AC/DC Switching Power Supply with 100 to 240V AC Rate Voltage and 12W Power
AC/DC Switching Power Supply with 100 to 240V AC Rate Voltage and 12W Power

AC/DC Switching Power Supply with 100 to 240V AC Rate Voltage and 12W Power

Get Latest Price
Payment Type:
Telegraphic Transfer in Advance (Advance TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer in Advance (Advance TT, T/T)
Product Description
Product Description
  • Features:
    • High-efficiency, ultrasonic lamination, natural cooling
    • High-reliability, ultra no-load/standby power consumption, meets green power requirements
    • Light and convenient plug-in
    • Online LED power indicator
    • Supports CE, CB, UL, FCC, CCC, GS, KS and SAA tests
    • Suitable for CD&DVD,MP3/MP4,Digital camera, communication terminals and more
  • Specifications :
    • Color: as the picture
    • Label: customized
    • MOQ: 100pcs
    • Warranty: 3 years
    • Input:
      • Input voltages: 90 to 264V AC, 50 to 60Hz
      • Rate voltages: 100 to 240V
      • Input current : 0.4A, maximum
      • Inrush current: ≤20A
      • Leakage current:
      • Output:
        • Maximum power: 12W
        • Output voltage: 5V DC ± 5%
        • Ripple wave (mVp-p): ≤100mV
        • Linear modulate: ±5%, maximum
        • Temperature coefficient: ±0.02%/°C
        • Start time: ≤3s (100V AC input, full load)
        • Guard time: ≥20ms (240V AC input, full load)
        • Output standard: 5V, 2.4A
      • Protection:
        • Over-ride, 115% to 200%VA, automatic recovery
        • Short-circuit protection, 1 channel: automatic recovery
      • Insulation:
        • Insulation strength: 3000V AC/5mA, 1min
        • Insulation resistance: ≥30mΩ, 500V DC
      • Environment:
        • Working temperatures: 0 to 40°C, 20m to 90% RH, non-condensing
        • Store temperatures: -20 to 80°C, 20% to 90% RH, non-condensing
      • Standards:
        • Safety standards
        • GB4943-2001 IEC60950
        • EMC En55022
      • Efficiency: ≥80%
      • Dimensions (L x W x H): 90 x 43 x 33mm
      • Packaging: polybag, color box, blister or customized
      • Delivery time: 7 to 12 working days
  • High-efficiency, ultrasonic lamination, natural cooling
  • High-reliability, ultra no-load/standby power consumption, meets green power requirements
  • Light and convenient plug-in
  • Online LED power indicator
  • Supports CE, CB, UL, FCC, CCC, GS, KS and SAA tests
  • Suitable for CD&DVD,MP3/MP4,Digital camera, communication terminals and more
  • Color: as the picture
  • Label: customized
  • MOQ: 100pcs
  • Warranty: 3 years
  • Input:
    • Input voltages: 90 to 264V AC, 50 to 60Hz
    • Rate voltages: 100 to 240V
    • Input current : 0.4A, maximum
    • Inrush current: ≤20A
    • Leakage current:
    • Output:
      • Maximum power: 12W
      • Output voltage: 5V DC ± 5%
      • Ripple wave (mVp-p): ≤100mV
      • Linear modulate: ±5%, maximum
      • Temperature coefficient: ±0.02%/°C
      • Start time: ≤3s (100V AC input, full load)
      • Guard time: ≥20ms (240V AC input, full load)
      • Output standard: 5V, 2.4A
    • Protection:
      • Over-ride, 115% to 200%VA, automatic recovery
      • Short-circuit protection, 1 channel: automatic recovery
    • Insulation:
      • Insulation strength: 3000V AC/5mA, 1min
      • Insulation resistance: ≥30mΩ, 500V DC
    • Environment:
      • Working temperatures: 0 to 40°C, 20m to 90% RH, non-condensing
      • Store temperatures: -20 to 80°C, 20% to 90% RH, non-condensing
    • Standards:
      • Safety standards
      • GB4943-2001 IEC60950
      • EMC En55022
    • Efficiency: ≥80%
    • Dimensions (L x W x H): 90 x 43 x 33mm
    • Packaging: polybag, color box, blister or customized
    • Delivery time: 7 to 12 working days
  • Input voltages: 90 to 264V AC, 50 to 60Hz
  • Rate voltages: 100 to 240V
  • Input current : 0.4A, maximum
  • Inrush current: ≤20A
  • Leakage current:
  • Output:
    • Maximum power: 12W
    • Output voltage: 5V DC ± 5%
    • Ripple wave (mVp-p): ≤100mV
    • Linear modulate: ±5%, maximum
    • Temperature coefficient: ±0.02%/°C
    • Start time: ≤3s (100V AC input, full load)
    • Guard time: ≥20ms (240V AC input, full load)
    • Output standard: 5V, 2.4A
  • Protection:
    • Over-ride, 115% to 200%VA, automatic recovery
    • Short-circuit protection, 1 channel: automatic recovery
  • Insulation:
    • Insulation strength: 3000V AC/5mA, 1min
    • Insulation resistance: ≥30mΩ, 500V DC
  • Environment:
    • Working temperatures: 0 to 40°C, 20m to 90% RH, non-condensing
    • Store temperatures: -20 to 80°C, 20% to 90% RH, non-condensing
  • Standards:
    • Safety standards
    • GB4943-2001 IEC60950
    • EMC En55022
  • Efficiency: ≥80%
  • Dimensions (L x W x H): 90 x 43 x 33mm
  • Packaging: polybag, color box, blister or customized
  • Delivery time: 7 to 12 working days
  • Maximum power: 12W
  • Output voltage: 5V DC ± 5%
  • Ripple wave (mVp-p): ≤100mV
  • Linear modulate: ±5%, maximum
  • Temperature coefficient: ±0.02%/°C
  • Start time: ≤3s (100V AC input, full load)
  • Guard time: ≥20ms (240V AC input, full load)
  • Output standard: 5V, 2.4A
  • Over-ride, 115% to 200%VA, automatic recovery
  • Short-circuit protection, 1 channel: automatic recovery
  • Insulation strength: 3000V AC/5mA, 1min
  • Insulation resistance: ≥30mΩ, 500V DC
  • Working temperatures: 0 to 40°C, 20m to 90% RH, non-condensing
  • Store temperatures: -20 to 80°C, 20% to 90% RH, non-condensing
  • Safety standards
  • GB4943-2001 IEC60950
  • EMC En55022
