Product Description

Tech-descriptions:

Universal Input voltage range

High efficiency and reliability

Small size and low profile

High power density

Low lose in empty load

AC inlet: AU, UK, US and EU

MTBF demonstrated: >35,000 hours

Mode: JX-B05020A-2-A

Input input voltages: AC 90-264V AC, 50-60HZ

Rate voltages: 100-240V

Input current: 0.5Max

Inrush current: ≤20A

Leakage current: <1mA

Output max power: 10W

Output voltage: DC 5V±5%

Ripple wave (mVp-p): ≤100mV

Line modulate: ±5% max

Temperature coefficient: ±0.02%/°C

Start time: ≤3s (100V AC input, full load)

Guard time: ≥20ms (240V AC input, full load)

Output standard: 5V/2A

Protection override protection: 115-200%VA, automatic recovery

Short-circuit protection 1 channel: Automatic recovery

Insulation Insulation strength: 3,000V AC/5mA,1 min

Insulation resistance: ≥30MΩ,DC500V

Enviornment working temperatures: 0-40°C, 20-90% RH non-condensing

Store temperatures: -20-80°C, 20-90% RH non-condensing

Standards safety standards: GB4943-2001 IEC60950

EMC: GB9254-2008 GB17625-2003 EN55022

Efficiency: ≥72%

Size (L x W x H): 62 x 41.5 x 29mm
