MPT Metalized Polypropylene Axial Film Capacitor for Welder Machine, Good Self-healing

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C

Product Description

Specifications:

Climate conditions: 40 to 85/110°C
Rated voltage: 100, 250, 400, 630V ,1000V DC
Capacitance range: 0.010 to 40¼F
Capacitance tolerance: ±5% (J), ±10%, (K)
Voltage-proof: 1.6UR (5 seconds)
Dissipation factor: d0.0010 1kHz, 20°C
Temperature: 40 ±2°C
Humidity: 93% RH
Lasting time: 21 days
There is no visible damage with the clearly mark
Capacitance: ”C/Cd5%
Dissipation factor (1kHz): increasing d0.002
IR insulation resistance: e50% of rated
Endurance test: +85/110°C, 1,000 hours
Applying voltage: 1.25 x rate voltage
Capacitance: ”C/Cd5%
Insulation resistance: e50% of rated
Structures:
- Material: polypropylene film
- Electrode: metalized vacuum evaporated layer
- Encapsulation: wrap up with PET tape and
- Encapsulated with passive flammability epoxy resin
- Shape: cylinder or elliptic
- Pin: cp leads or PVC
- Electronic tread
Using area:
- In heavy current such as filtering and impulse
- Power amplifiers and welder machines and more could be used inall the
- CBB21 complaint conditions

Features:

Small size with good self-healing effect, very low-loss athigh-frequency could bear the high-current impactive
Have well voltage-proof features under the high-frequency ACcurrent

Climate conditions: 40 to 85/110°C

Rated voltage: 100, 250, 400, 630V ,1000V DC

Capacitance range: 0.010 to 40¼F

Capacitance tolerance: ±5% (J), ±10%, (K)

Voltage-proof: 1.6UR (5 seconds)

Dissipation factor: d0.0010 1kHz, 20°C

Temperature: 40 ±2°C

Humidity: 93% RH

Lasting time: 21 days

There is no visible damage with the clearly mark

Capacitance: ”C/Cd5%

Dissipation factor (1kHz): increasing d0.002
