0.91-inch OLED Display Module with SH1106 Driver IC, Wide Viewing Angle, Long and Narrow ShapeNew

Get Latest Price

Payment Type:: 30% Deposit or 70% T/T before Shipment

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	30% Deposit or 70% T/T before Shipment

Product Description

Overview:

This is a monochrome OLED display module with 128 x 32 dot matrix
Characteristics: high-brightness, self-emission, high-contrast ratio, slim/thin outline, wide viewing angle, wide temperature range and low-power consumption

Features:

Display color: white
Driver IC: SH1106G
Interface: I2C
Operating temperature: -40 to 70°C

Mechanical data:

Dot matrix (W x H): 128 x 32
Dot size (W x H): 0.159 x 0.159mm
Dot pitch (W x H): 0.175 x 0.175mm
Aperture rate: 82%
Active area (W x H): 22.38 x 5.58mm
Panel size (W x H x T): 30 x 11.5 x 1.05mm
Module size (W x H x T): 40.5 x 11.5 x 1.28mm
Diagonal A/A size: 0.91-inch
Module weight: 0.88 ± 10%g

This is a monochrome OLED display module with 128 x 32 dot matrix

Characteristics: high-brightness, self-emission, high-contrast ratio, slim/thin outline, wide viewing angle, wide temperature range and low-power consumption

Display color: white

Driver IC: SH1106G

Interface: I2C

Operating temperature: -40 to 70°C

Dot matrix (W x H): 128 x 32

Dot size (W x H): 0.159 x 0.159mm

Dot pitch (W x H): 0.175 x 0.175mm

Aperture rate: 82%

Active area (W x H): 22.38 x 5.58mm

Panel size (W x H x T): 30 x 11.5 x 1.05mm

Module size (W x H x T): 40.5 x 11.5 x 1.28mm

Diagonal A/A size: 0.91-inch
