Aluminum PCB of Ceramic Substrate, with test voltage of 10 to 300V

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T

Product Description

Key specification:

Base material: FR-4, FR2, Taconic, Rogers, CEM-1 CEM-3

Copper thickness: 1/2 oz min;12 oz max

Board thickness: 0.2mm-6.00 mm(8mil-126mil)

Min. hole size: 0.1mm(4mil)

Min. line width: 0.075mm(3mil)

Min. line spacing: 0.1mm4mil)

Surface finishing: immersion gold/Au,HASL,OSP,etc.

Warp & twist: 0.7%

Hole position: +/-0.075mm(3mil) CNC Driling

Insulation resistance: 10Kohm-20Mohm

Conductivity: <50ohm

Test voltage: 10-300V

Impedance control: +/-10%

Outline tolerance:0.125mm(5mil)

CNC routing;+/-0.15mm(6mil) by punching

Hole diameter (H): PTH L:+/-0.075mm(3mil); Non-PTH L:+/-0.05mm(2mil)

Conductor width (W): +/-20% of original artwork PTH L:+/-0.075mm(3mil)
