16CH network video recorder, ONVIF P2P, adapted H.264 video compression and G.711 audio compression

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, PayPal or Western Union

Product Description

Main specifications:

IPC input: 16CH D1/16CH 720p/8CH 1080p at 30fps
Protocol supports: ONVIF core spec 2.2 compatible with standard ONVIF IP cameras
Intercom: 1CH RCA
CVBS output: 1CH BNC (1.0Vp-p, 75Ω)
VGA/HDMI output: 1CH, resolution optional (1920x1080, 1280x1024, 1280x720, 1024x768 and 800x600p)
Audio output: 1CH RCA interface
Video compression: H.264/MPEG 4 AVC, up to main profile 5.0
Video resolution: 5/3MP, 1080/960/720p, VGA/4CIF/DCIF/2CIF/CIF/QCIF
Stream type: composite audio stream
Local playback: 1 to 8CH sync playback
Mobile surveillance: supports iPhone, Android, Symbian, Windows and Blackberry
DDNS/P2P: supported
SATA interface: 4 SATA (8 SATA is optional)
Alarm input: 8CH
Alarm output: 3CH

Functions:

Supports ONVIF protocol and compatible with standard ONVIF IP cameras
Supports P2P, built-in free DDNS
High-performance CPU, supports TV/VGA/HDMI simultaneously output
Adapted H.264 video compression and G.711 audio compression and can decoding HD resolution video
Graphic operation interface supports front panel, remote and mouse operation
Supports varied video reach, local and network playback
Supports mobile phone remote monitoring

IPC input: 16CH D1/16CH 720p/8CH 1080p at 30fps

Protocol supports: ONVIF core spec 2.2 compatible with standard ONVIF IP cameras

Intercom: 1CH RCA

CVBS output: 1CH BNC (1.0Vp-p, 75Ω)

VGA/HDMI output: 1CH, resolution optional (1920x1080, 1280x1024, 1280x720, 1024x768 and 800x600p)

Audio output: 1CH RCA interface

Video compression: H.264/MPEG 4 AVC, up to main profile 5.0

Video resolution: 5/3MP, 1080/960/720p, VGA/4CIF/DCIF/2CIF/CIF/QCIF

Stream type: composite audio stream

Local playback: 1 to 8CH sync playback

Mobile surveillance: supports iPhone, Android, Symbian, Windows and Blackberry

DDNS/P2P: supported
