1.44-inch Mobile Phone LCD Module, 128 x RGB x 128P Resolution, LED BacklightNew
  • 1.44-inch Mobile Phone LCD Module, 128 x RGB x 128P Resolution, LED BacklightNew
  • 1.44-inch Mobile Phone LCD Module, 128 x RGB x 128P Resolution, LED BacklightNew
  • 1.44-inch Mobile Phone LCD Module, 128 x RGB x 128P Resolution, LED BacklightNew
  • 1.44-inch Mobile Phone LCD Module, 128 x RGB x 128P Resolution, LED BacklightNew
  • 1.44-inch Mobile Phone LCD Module, 128 x RGB x 128P Resolution, LED BacklightNew
1.44-inch Mobile Phone LCD Module, 128 x RGB x 128P Resolution, LED BacklightNew
1.44-inch Mobile Phone LCD Module, 128 x RGB x 128P Resolution, LED BacklightNew
1.44-inch Mobile Phone LCD Module, 128 x RGB x 128P Resolution, LED BacklightNew
1.44-inch Mobile Phone LCD Module, 128 x RGB x 128P Resolution, LED BacklightNew
1.44-inch Mobile Phone LCD Module, 128 x RGB x 128P Resolution, LED BacklightNew

1.44-inch Mobile Phone LCD Module, 128 x RGB x 128P Resolution, LED BacklightNew

Payment Type:
Telegraphic Transfer (TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer (TT,T/T)
Product Description
Product Description
  • Screen size: 1.44-inch (diagonal)
  • Resolution: 128 x RGB x 128 pixels
  • Display modes: normally white, transmissive
  • Driver element: a-Si TFT active matrix
  • Color depth: 262K
  • Viewing direction: 12 O' clock
  • Viewing angle: (L/R/U/D) 50/50/50/30°
  • Brightness: 200cd/m²
  • Color configuration RGB vertical stripe
  • Backlight unit: LED x 2 pieces
  • Interface: MCU 80-system 8-bit data bus 18 pins
  • Touch panel: without (touch panel mode for wire resistance/optional)
  • Drive IC ST7735R
  • Dimensions:
    • Outline: 30.30x34.41x2.4mm
    • Viewing area: 25.49x26.49mm
    • Active area: 25.49x26.49mm
    • Pixel pitch: 0.0727x0.219mm
    • Dots size: 0.0607x0.207mm
  • Outline: 30.30x34.41x2.4mm
  • Viewing area: 25.49x26.49mm
  • Active area: 25.49x26.49mm
  • Pixel pitch: 0.0727x0.219mm
  • Dots size: 0.0607x0.207mm
