LED Display with IP65 Waterproof and 25 to 120M Best Viewing Distance, CE/RoHS-marked

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Features:

Pixel pitch: 25mm
Resolution: 8 x 8 pixels
Module size: 200 x 200mm
Pixel configuration: 2R1G1B
Density: 1,600 dots/m²

Cabinet parameters:

Cabinet size: 1,200 x 1,200mm
Cabinet resolution: 32 x 32 pixels
Module quality: 4 x 4 pieces

Main technical parameters:

LED standard: DIP546
Best viewing distance: 25 to 120m
Best viewing angle:
- Horizontal: 110°
- Vertical: 45°
Brightness: ≥4,000cd/m²
Drive mode: constant driving, static latch
Exchange frame frequency: ≥60Hz
Refresh rate: ≥480Hz
Grey grade: 1,024 levels
Protection rate: PI65
Control mode: synchronization
Working voltage: 380 ±10V
Maximum power consumption: 500W/m²
Working environment temperature: -20 to 50°C
Screen lifespan: ≥100.000 hours
Blind dot rate: below 0.0003
Computer operating system: Microsoft's Windows 98, XP, 2000 and more
Video signal: RF, S-video, RGB, RGBHV, YUV and more
Control system: DVI graphics card + sending card + receiving card PC display mode
Software: LED studio
With CE, RoHS, FCC marks
