Product Description

Specifications:

P7.62mm SMD indoor full color LED display
Pixel pitch: 7.62mm
Brightness: ≥1,300cd/m²
Power consumption: 800W (maximum)
Power consumption: 300W (average)
Pixel composing: 1R1P1B
LED type: SMD
Resolution: 17,222 pixel dots/m²
Best viewing distance: 7 to 50 meters
Viewing angle:
- Horizontal: 100°
- Vertical: 120°
Module dimension: 244 x 122mm
Module resolution: 32 x 16 pixels dots
Cabinet dimension: 732 x 488mm
Cabinet resolution: 96 x 64 pixel dots
Working temperatures: -20 to 60°C
Heat treatment with fans inside
IP rating: IP43
Driving IC: 5020
Driving mode: constant current
Scanning way: 1/8
Brightness adjustment: automatic and manual (by software)
Lifespan: ≥100,000 hours
MTBF: ≥5,000 hours
Displaying colors: 1,024 x 1,024 x 1,024
Signal interface: DVI
Control system: synchronous control system
Data communication: optical fiber
Available signals: RF, S-video, RGB, RGBHV, HDTV, DVD, camera, DVI, and more

All trademarks shown here are for reference purposes only. They are the property of their respective owners, and we are not authorized to sell items bearing such trademarks.

P7.62mm SMD indoor full color LED display

Pixel pitch: 7.62mm

Brightness: ≥1,300cd/m²

Power consumption: 800W (maximum)

Power consumption: 300W (average)

Pixel composing: 1R1P1B

LED type: SMD

Resolution: 17,222 pixel dots/m²

Best viewing distance: 7 to 50 meters

Viewing angle:

Horizontal: 100°
Vertical: 120°

Module dimension: 244 x 122mm

Module resolution: 32 x 16 pixels dots

Cabinet dimension: 732 x 488mm

Cabinet resolution: 96 x 64 pixel dots

Working temperatures: -20 to 60°C

Heat treatment with fans inside

IP rating: IP43

Driving IC: 5020

Driving mode: constant current

Scanning way: 1/8

Brightness adjustment: automatic and manual (by software)

Lifespan: ≥100,000 hours

MTBF: ≥5,000 hours

Displaying colors: 1,024 x 1,024 x 1,024

Signal interface: DVI

Control system: synchronous control system

Data communication: optical fiber

Available signals: RF, S-video, RGB, RGBHV, HDTV, DVD, camera, DVI, and more

Horizontal: 100°

Vertical: 120°
