Ph6 SMD LED Screen for Rental Business, 3528 SMD, 1R1G1B, 3-in-1, CE, RoHS, FCC Certificates

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Specifications:

Pixel pitch: 6mm
Resolution: 32 x 16mm
Module size: 192 x 96mm
Pixel configuration: 1R1G1B
Density: 27,777dots/m²
Cabinet parameters:
- Cabinet size: 768 x 576mm
- Cabinet resolution: 128 x 96mm
- Module quantity: 4 x 6 pieces
LED standard: SMD 3528
Best viewing distance: 3 to 38m
Viewing angle:
- Horizontal: 150°
- Vertically: 120°
Brightness: ≥2,000cd/m²
Mode: constant driving 1/8 scans
Rate: ≥800Hz
Refresh frequency: ≥72Hz
Grey grade: ≥10,24-level
Protection rate: IP31
Control mode: synchronization
Working voltage: 220/380V AC ± 10％, 50Hz
Maximum power consumption: ≤1,200W/m²
Working environment temperature: -20 to 50°
Lifetime: ≥100,000 hours
DOT rate: below 0.0001
Computer operating systems: Microsoft's Windows 98, XP, 2000 and more
Video signal: RF, s-video, RGB, RGBHV, YUV and more
System: DVI graphics card + sending card + receiving card
With CE, RoHS, FCC certifications

All trademarks shown here are for reference purposes only. They are the property of their respective owners, and we are not authorized to sell items bearing such trademarks.
