P6 LED Display/Screen/Sign with SMD 3-in-1, 6mm Pixel Pitch and 60 to 85Hz Frame Frequency
  • P6 LED Display/Screen/Sign with SMD 3-in-1, 6mm Pixel Pitch and 60 to 85Hz Frame Frequency
P6 LED Display/Screen/Sign with SMD 3-in-1, 6mm Pixel Pitch and 60 to 85Hz Frame Frequency

P6 LED Display/Screen/Sign with SMD 3-in-1, 6mm Pixel Pitch and 60 to 85Hz Frame Frequency

Get Latest Price
Payment Type:
Telegraphic Transfer in Advance (Advance TT, T/T)
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: Telegraphic Transfer in Advance (Advance TT, T/T)
Product Description
Product Description
  • Specifications:
    • Pixel pitch: 6mm
    • SMD 3-in-1
    • Pixel construction: one chip with 3 color (3-in-1)
    • Module resolution (L x H): 32 x 16mm: 512 pixel dots
    • Brightness of white: 2,000cd/sqm at least
    • The optimal viewing distance: 3 to 38 meters
    • Grey scale: 10-bits/1,024-levels
    • Display color: 1,024 x 1,024 x 1,024: 1 billion
    • Viewing angle (H/V): 150/120 degrees
    • Refresh rate: 240Hz at least
    • Driving mode: constant driving 1/8 scan
    • Brightness adjustment: 0 to 100% with 8 levels automatic
    • Gamma correction: -5.0 to 5.0
    • Correction scale level: 16 bits
    • Frame frequency: 60 to 85Hz
    • Color temperature: 5,000 to 9,300K (control by thesoftware)
    • Input source supported: S-video/VGA/DVI/SDI/HD-SDI
    • Lifetime: 100,000 hours at least
    • MTBF: 5,000 hours at least
    • Out of control rate: 3/10,000 at most
  • Pixel pitch: 6mm
  • SMD 3-in-1
  • Pixel construction: one chip with 3 color (3-in-1)
  • Module resolution (L x H): 32 x 16mm: 512 pixel dots
  • Brightness of white: 2,000cd/sqm at least
  • The optimal viewing distance: 3 to 38 meters
  • Grey scale: 10-bits/1,024-levels
  • Display color: 1,024 x 1,024 x 1,024: 1 billion
  • Viewing angle (H/V): 150/120 degrees
  • Refresh rate: 240Hz at least
  • Driving mode: constant driving 1/8 scan
  • Brightness adjustment: 0 to 100% with 8 levels automatic
  • Gamma correction: -5.0 to 5.0
  • Correction scale level: 16 bits
  • Frame frequency: 60 to 85Hz
  • Color temperature: 5,000 to 9,300K (control by thesoftware)
  • Input source supported: S-video/VGA/DVI/SDI/HD-SDI
  • Lifetime: 100,000 hours at least
  • MTBF: 5,000 hours at least
  • Out of control rate: 3/10,000 at most
