Indoor P4 Full Color Display, 2 to 20m Best Viewing Distance, 32 x 32-pixel Resolution

Get Latest Price

Payment Type:: Telegraphic Transfer in Advance (Advance TT, T/T)

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Specifications:

Best viewing distance: 2 to 20m
Resolution: 32 x 32 pixels
Pitch: 4mm
Module size: 128 x 128m
Pixel configuration: 3-in-1
Density: 62,500-dot/m²
Best viewing angle:
- Horizontal: 150°
- Vertically: 120°
Maximum power consumption: ≤2,000W/sq.M
Brightness: ≥2,500cd/m²
Control mode: synchronization
Drive mode: constant driving 1/16 scan
Exchange frame rate: ≥2Hz
Refresh rate: ≥560Hz
Grey grade: 16,384 levels
Protection time: PI3 1
Working environment temperature: -20 to 50°C
Working voltage: 220/380V AC, ± 10％，50Hz
Screen lifetime: 100 thousand hours blind dot
Rate: below 0.0001
Computer operating systems: Microsoft's Windows 98, XP, 2000 and more
Video signal: RF, S-video, RGB, RGBHV, YUV and more
Control system: DVI graphics card + sending card + receiving card
Certificates: CE, RoHS and FCC

All trademarks shown here are for reference purposes only. They are the property of their respective owners, and we are not authorized to sell items bearing such trademarks.

Best viewing distance: 2 to 20m

Resolution: 32 x 32 pixels

Pitch: 4mm

Module size: 128 x 128m

Pixel configuration: 3-in-1

Density: 62,500-dot/m²

Best viewing angle:

Horizontal: 150°
Vertically: 120°

Maximum power consumption: ≤2,000W/sq.M

Brightness: ≥2,500cd/m²

Control mode: synchronization

Drive mode: constant driving 1/16 scan

Exchange frame rate: ≥2Hz

Refresh rate: ≥560Hz

Grey grade: 16,384 levels

Protection time: PI3 1

Working environment temperature: -20 to 50°C

Working voltage: 220/380V AC, ± 10％，50Hz

Screen lifetime: 100 thousand hours blind dot

Rate: below 0.0001

Computer operating systems: Microsoft's Windows 98, XP, 2000 and more

Video signal: RF, S-video, RGB, RGBHV, YUV and more

Control system: DVI graphics card + sending card + receiving card

Certificates: CE, RoHS and FCC

Horizontal: 150°

Vertically: 120°
