LED Outdoor Digital Full Color Video Billboard with PC Control Software

Get Latest Price

Payment Type:: T/T, L/C

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C

Product Description

Specifications:

Pixel pitch: 16mm
Pixel density: 3,906
Brightness: 9,000 nits
Color temperature: 5,000 to 9,300K (chosen by user in thesoftware)
Brightness adjustment: automatically or manually
Horizontal: 110Ú
Vertical: 50Ú
Viewing distance: 10 to 300 meters
Optimum viewing distance: 15 to 200m
Scanning method: static
Driving method: constant current
Driving IC: MBI5026 or Toshiba
Gray grades: 256 for RGB
Display color: 17 millions
Refresh frequency: more than 180Hz
Picture display method: dots to dots display synchronized withCRT
Signal interface: DVI and VGA (can be customized)
Input signal:
- Video: PAL/NTSC
- Optional: VGA, video, DVD, TV, and others (the video processorcan be customized)
Video processor availability
Display format: 800 x 600, 1,024 x 768, and 1,280 x 1,024pixels
Software: Microsoft's Windows series system
Protection grade: IP65 (waterproof and dust-proof)
Working temperature: -20 to 50°C
Humidity: 10 to 95% RH
Stored temperature: -50 to 70°C
Screen lifespan: e 100,000 hours
Out of controlled dots: d3/10,000, out of controlled dots meansthe pixels of which the brightness and wave length are both 10%depart to the normal one
Whole display flatness: less than 1mm juncture
Maintenance way: back or front maintenance, moduledisplaced
Switch power supply: 110 to 220V, 50 to 60Hz
Power consumption:
- Maximum: 1,300W
- Average: 400 to 800W

All trademarks shown here are for reference purposesonly. They are the property of their respective owners, and we arenot authorized to sell items bearing such trademarks.

Pixel pitch: 16mm

Pixel density: 3,906

Brightness: 9,000 nits

Color temperature: 5,000 to 9,300K (chosen by user in thesoftware)

Brightness adjustment: automatically or manually

Horizontal: 110Ú

Vertical: 50Ú

Viewing distance: 10 to 300 meters

Optimum viewing distance: 15 to 200m

Scanning method: static

Driving method: constant current

Driving IC: MBI5026 or Toshiba

Gray grades: 256 for RGB

Display color: 17 millions

Refresh frequency: more than 180Hz

Picture display method: dots to dots display synchronized withCRT

Signal interface: DVI and VGA (can be customized)

Input signal:

Video: PAL/NTSC
Optional: VGA, video, DVD, TV, and others (the video processorcan be customized)

Video processor availability

Display format: 800 x 600, 1,024 x 768, and 1,280 x 1,024pixels

Software: Microsoft's Windows series system

Protection grade: IP65 (waterproof and dust-proof)

Working temperature: -20 to 50°C

Humidity: 10 to 95% RH

Stored temperature: -50 to 70°C

Screen lifespan: e 100,000 hours

Out of controlled dots: d3/10,000, out of controlled dots meansthe pixels of which the brightness and wave length are both 10%depart to the normal one

Whole display flatness: less than 1mm juncture

Maintenance way: back or front maintenance, moduledisplaced

Switch power supply: 110 to 220V, 50 to 60Hz

Power consumption:
