Standalone DVR, Encode Capacity, 24CH CIF Real-time, Decode Capacity, 8CH CIF Real-time

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Specifications:

Model: J-9324H (HI3520A)
System:
- Main processor: industrial embedded microcontroller Huawei Hass platform
- Operating system: embedded Linux
- System resources: simultaneous multi-channel real-time recording, playback, network operating, USB backup
Interface:
- User interface: support 16-bit true color graphical menu interface and mouse operating
- Preview screen: 1/4/8/9/16/24/32 (under analog mode)
Video:
- Video standards: PAL (625 lines, 50fps), NTSC (525 lines, 60fps)
- Video compression: H.264 (high-profile)
- Display quality: monitor: D1, VGA, HDMI: HD (maximum 1,920 x 1,080 pixels)
- Play quality: D1/HD1/CIF/QCIF
- Encode capacity: 24-channel CIF real-time
- Decode capacity: 8-channel CIF real-time
- Hybrid mode: only analog (DVR) 24 x CIF
- Only IP (NVR): 9 x D1/8 x 960H/4 x 720P/2 x 1,080P/1 x 720P + 7 x D1/1 x 1,080P + 1 x 720P + 2 x D1
- Motion detect: zones: 192 (16 x 12) detection zones, sensitivity: multi-level sensitivity (only local channels)
Audio:
- Audio compression: G.711A
- Bidirectional talk supported
Record and playback:
- Record mode: manual, alarm, motion detection, timing
- Local playback: 1 to 9-channel playback, under analog mode 24 x CIF, up to 8-channel playback (8 x CIF at 25fps)

Model: J-9324H (HI3520A)

System:

Main processor: industrial embedded microcontroller Huawei Hass platform
Operating system: embedded Linux
System resources: simultaneous multi-channel real-time recording, playback, network operating, USB backup

Interface:

User interface: support 16-bit true color graphical menu interface and mouse operating
Preview screen: 1/4/8/9/16/24/32 (under analog mode)

Video:

Video standards: PAL (625 lines, 50fps), NTSC (525 lines, 60fps)
Video compression: H.264 (high-profile)
Display quality: monitor: D1, VGA, HDMI: HD (maximum 1,920 x 1,080 pixels)
Play quality: D1/HD1/CIF/QCIF
Encode capacity: 24-channel CIF real-time
Decode capacity: 8-channel CIF real-time
Hybrid mode: only analog (DVR) 24 x CIF
Only IP (NVR): 9 x D1/8 x 960H/4 x 720P/2 x 1,080P/1 x 720P + 7 x D1/1 x 1,080P + 1 x 720P + 2 x D1
Motion detect: zones: 192 (16 x 12) detection zones, sensitivity: multi-level sensitivity (only local channels)

Audio:

Record and playback:

Record mode: manual, alarm, motion detection, timing
Local playback: 1 to 9-channel playback, under analog mode 24 x CIF, up to 8-channel playback (8 x CIF at 25fps)

Main processor: industrial embedded microcontroller Huawei Hass platform

Operating system: embedded Linux

System resources: simultaneous multi-channel real-time recording, playback, network operating, USB backup

User interface: support 16-bit true color graphical menu interface and mouse operating

Preview screen: 1/4/8/9/16/24/32 (under analog mode)

Video standards: PAL (625 lines, 50fps), NTSC (525 lines, 60fps)

Video compression: H.264 (high-profile)

Display quality: monitor: D1, VGA, HDMI: HD (maximum 1,920 x 1,080 pixels)

Play quality: D1/HD1/CIF/QCIF

Encode capacity: 24-channel CIF real-time

Decode capacity: 8-channel CIF real-time

Hybrid mode: only analog (DVR) 24 x CIF

Only IP (NVR): 9 x D1/8 x 960H/4 x 720P/2 x 1,080P/1 x 720P + 7 x D1/1 x 1,080P + 1 x 720P + 2 x D1

Motion detect: zones: 192 (16 x 12) detection zones, sensitivity: multi-level sensitivity (only local channels)

Audio compression: G.711A

Bidirectional talk supported

Record mode: manual, alarm, motion detection, timing

Local playback: 1 to 9-channel playback, under analog mode 24 x CIF, up to 8-channel playback (8 x CIF at 25fps)
