Selectable Frequency Quad Photoelectric Beams Sensor

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T 10 Days in Advance

Product Description

Main features:

Parameter:

Selection of high-performance infrared transmit/receive geminate transistors

New parasitic light wave filtering face-piece

Effectively filter out parasitic light interference

High-performance MCU control, digital line treatment

Signal selectable frequency mode, high immunity to interference

Simple, convenient installation and adjustment

4 channel switch

Model no.: SBQ-75F/SBQ-100F/SBQ-150F/SBQ-200F/SBQ-250F

Protection range: 75m/100m/150m/200m/250m

Distance allowance: 1000m/1400m/2100m/2800m/3500m

Detection system: Alarm when 4 beams cut simultaneously

Select channel: 4 channel switch

Response time: 30-960ms

Operating voltage: DC 10.5~28V, (12V recommended)

Current consumption: Max 65mA 70mA 90mA 95mA 100mA

Optical axis horizontal adjust: 180°( ±90°)

Optical axis vertical adjust: 24°( ±12°)

Alarm output: Relay contact output 1C, NC/NO, contact rating AC, DC30V, 0.5Amax

Tamper output: Output 1B, contact rating DC 30V 0.5A MAX

Collimator: View finder

Operation temperatures: -25ºC~+55ºC, RH under 95%

Output dimension: 355(H) X 99(W) X 104(D) mm

Weight: Transmitter 980g, receiver 1050g
