Stability Triple Photoelectric Beam Sensor With Fresnel Lens
  • Stability Triple Photoelectric Beam Sensor With Fresnel Lens
Stability Triple Photoelectric Beam Sensor With Fresnel Lens

Stability Triple Photoelectric Beam Sensor With Fresnel Lens

Get Latest Price
Payment Type:
T/T 10 Days in Advance
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T 10 Days in Advance
Product Description
Product Description
  • Main features:
    • Selection of high-performance infrared transmit/receive geminate transistors
    • New parasitic light wave filtering face-piece
    • effectively filter out parasitic light interference
    • Optical axis can be adjusted all-round
    • Collimator with high-precision configuration
    • improve the calibration rate of the optical axis
    • LED status equipment, easy to install and detect
    • Used in longer distance protection
  • Technical parameters:
    • Model no.: SBM-50/SBM-75/SBM-100/SBM-150
    • Protection range: 50/75/100/150m
    • Distance allowance: 1,000/1,500/2,000/3,000m
    • Detection system: Alarm when 3 beams cut simultaneously
    • Response time: 35-700ms
    • Operating voltage: DC 10.5~28V, (12V recommended)
    • Current consumption max: 70/80/90/100mA
    • Optical axis horizontal adjust:180° ( ±90°)
    • Optical axis vertical adjust:16° ( ±8°)
    • Alarm output: Relay contact output 1C, NC/NO, contact rating AC, DC30V, 0.5A max
    • Tamper output: Output 1B, contact rating DC 30V 0.5A max
    • Collimator: View finder
    • Operation temperature: -25-55ºC,RH under 95%
    • Output dimension: 270(H) X 90(W) X 90(D) mm
    • Weight: Transmitter 530g, receiver 550g
  • Selection of high-performance infrared transmit/receive geminate transistors
  • New parasitic light wave filtering face-piece
  • effectively filter out parasitic light interference
  • Optical axis can be adjusted all-round
  • Collimator with high-precision configuration
  • improve the calibration rate of the optical axis
  • LED status equipment, easy to install and detect
  • Used in longer distance protection
  • Model no.: SBM-50/SBM-75/SBM-100/SBM-150
  • Protection range: 50/75/100/150m
  • Distance allowance: 1,000/1,500/2,000/3,000m
  • Detection system: Alarm when 3 beams cut simultaneously
  • Response time: 35-700ms
  • Operating voltage: DC 10.5~28V, (12V recommended)
  • Current consumption max: 70/80/90/100mA
  • Optical axis horizontal adjust:180° ( ±90°)
  • Optical axis vertical adjust:16° ( ±8°)
  • Alarm output: Relay contact output 1C, NC/NO, contact rating AC, DC30V, 0.5A max
  • Tamper output: Output 1B, contact rating DC 30V 0.5A max
  • Collimator: View finder
  • Operation temperature: -25-55ºC,RH under 95%
  • Output dimension: 270(H) X 90(W) X 90(D) mm
  • Weight: Transmitter 530g, receiver 550g
