Outdoor Decorative Antenna with N Female Connector, 7/10dBi Gain
  • Outdoor Decorative Antenna with N Female Connector, 7/10dBi Gain
Outdoor Decorative Antenna with N Female Connector, 7/10dBi Gain

Outdoor Decorative Antenna with N Female Connector, 7/10dBi Gain

Get Latest Price
Payment Type:
TT, Western Union, L/C at Sight, PayPal
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: TT, Western Union, L/C at Sight, PayPal
Product Description
Product Description
  • Description:
    • It's applied to the signal coverage in residential area, public square, the lawn and SM/CDMA/PCS/3G/WLAN system
  • Specifications:
    • Electrical:
      • Frequency range: 806-960/1,710-2,500MHz
      • Bandwidth: 154/790MHz
      • Gain: 7/10dBi
      • Vertical beam width: 55/45°
      • Horizontal beam width: 70/60°
      • VSWR: ≤1.5
      • Nominal impedance: 50Ω
      • Polarization: vertical
      • Maximum power: 50W
      • Connector: N-K
    • Mechanical:
      • Antenna dimensions: 650 x 540 x 70mm
      • Weight: 3.5kg
  • It's applied to the signal coverage in residential area, public square, the lawn and SM/CDMA/PCS/3G/WLAN system
  • Electrical:
    • Frequency range: 806-960/1,710-2,500MHz
    • Bandwidth: 154/790MHz
    • Gain: 7/10dBi
    • Vertical beam width: 55/45°
    • Horizontal beam width: 70/60°
    • VSWR: ≤1.5
    • Nominal impedance: 50Ω
    • Polarization: vertical
    • Maximum power: 50W
    • Connector: N-K
  • Mechanical:
    • Antenna dimensions: 650 x 540 x 70mm
    • Weight: 3.5kg
  • Frequency range: 806-960/1,710-2,500MHz
  • Bandwidth: 154/790MHz
  • Gain: 7/10dBi
  • Vertical beam width: 55/45°
  • Horizontal beam width: 70/60°
  • VSWR: ≤1.5
  • Nominal impedance: 50Ω
  • Polarization: vertical
  • Maximum power: 50W
  • Connector: N-K
  • Antenna dimensions: 650 x 540 x 70mm
  • Weight: 3.5kg
