2.4GHz Dual-band Panel Antenna with 2,400 to 2,500MHz Frequency Range, 17dBi Gain

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, Western Union, L/C at Sight

Product Description

Specification:

Applications:

Features:

Frequency range: 2,400 to 2,500MHz

Gain: 17dBi

Polarization: ±45°

VSWR: ≤1.5

Horizontal beam width: 90°

Vertical beam width: 6.5°

Port isolation: ≥30dB

F/B ratio: ≥25dB

Side lobe suppression for first side lobe above main beam: ≥15dB

Impedance: 50Ω

Maximum power capacity: 200W

Lighting protection: DC ground

Connector: type N-K

Antenna dimension: 1,160 x 132 x 62mm

Antenna weight: 3.9kg

Radome material and color: UPV light gray

Mechanical tilt: 15°

Pole diameter: Ø35 to 75mm

Rate wind velocity: 60m/second

Operating temperature: -40 to 60°C

Humidity: 5 to 95% RH

2.4GHz band

WLAN/Wi-Fi system/ISM band

Supports IEEE802.11b/g

Public hot-pot, sector cover

Point to multiple points

90° cover, dual-polarization, high-gain, low-VSWR

Provide adjustable angle installation kits

Anti-aging PVC cover
