Yagi Antenna with DC Ground Lightning Protection and 14dBi Gain, 150W Maximum Power
  • Yagi Antenna with DC Ground Lightning Protection and 14dBi Gain, 150W Maximum Power
Yagi Antenna with DC Ground Lightning Protection and 14dBi Gain, 150W Maximum Power

Yagi Antenna with DC Ground Lightning Protection and 14dBi Gain, 150W Maximum Power

Get Latest Price
Payment Type:
T/T, Western Union and L/C at Sight
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Payment Type: T/T, Western Union and L/C at Sight
Product Description
Product Description
  • Specifications:
    • Frequency range: 1,710 to 2,170MHz
    • Gain: 14dBi
    • Vertical beam width: 30°
    • Front to back ratio: ≥17dB
    • VSWR ≤1.5
    • Beam width: 31°
    • Input impedance: 50Ω
    • Polarization: vertical or horizontal
    • Maximum power: 150W
    • Connector: N-K
  • Mechanical:
    • Cable: 0.5m
    • Number of element: 14 elements
    • Rated wind velocity: 210km/hour
    • Weight: 0.34kg
    • Length: 690mm
    • Temperatures range: -40 to 60℃
    • Humidity range range: 5 to 95%
    • Installation: pole φ38 to 52
  • Frequency range: 1,710 to 2,170MHz
  • Gain: 14dBi
  • Vertical beam width: 30°
  • Front to back ratio: ≥17dB
  • VSWR ≤1.5
  • Beam width: 31°
  • Input impedance: 50Ω
  • Polarization: vertical or horizontal
  • Maximum power: 150W
  • Connector: N-K
  • Cable: 0.5m
  • Number of element: 14 elements
  • Rated wind velocity: 210km/hour
  • Weight: 0.34kg
  • Length: 690mm
  • Temperatures range: -40 to 60℃
  • Humidity range range: 5 to 95%
  • Installation: pole φ38 to 52
